Newland FM430 Barracuda Laser Aimer Fixed-Mount 2D Barcode Reader USB Kit
Brand:
Newland
NLS-FM430L-U
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Newland FM430 Barracuda Laser Aimer USB Kit
Fixed-mount 1D/2D barcode reader650 nm Class 2 laser1280 × 800 CMOS2 m USB extension cable
The Newland FM430 Barracuda NLS-FM430L-U is a fixed-mount 1D/2D barcode reader kit for kiosk, POS and embedded integrations. Its CMOS imager reads paper and mobile-screen barcodes, with white LED illumination and light/IR sensors. This exact kit has a laser aimer and includes a 2 m USB extension cable; it is a reader, not a complete kiosk or payment system.
Best For: For kiosk, POS and embedded-system integrators who need a fixed-mount 1D/2D reader with a laser aimer and USB extension. A compatible host, integration software and appropriate mounting design are required; host equipment and mounting accessories are not included.
Before you order: This is a fixed-mount reader, not a handheld terminal, complete kiosk, payment system, RFID reader or printer. A compatible host, integration software/setup and appropriate mounting design are required; host/kiosk/display equipment and mounting accessories are not included. Do not assume a bundled payment app or software licence. The kit includes the reader and 2 m USB extension cable; a serial cable and power adapter with interchangeable plugs are optional and not included. Follow the manufacturer's instructions and avoid staring into the Class 2 aiming beam. IP54 is not waterproofing or approval for unprotected outdoor exposure; the manufacturer calls for suitable additional housing for outdoor integration. The 1.5 m drop rating is not a damage guarantee.
What's in the Box
- FM430 Barracuda reader
- 2 m USB extension cable
What It Means in Practice
- Use the included 2 m USB extension cable for the USB installation.
- Example reading ranges depend on barcode type and module size: EAN-13 13 mil 55–360 mm, QR 15 mil 40–210 mm, and Data Matrix 10 mil 50–170 mm.
- The reader supports Sense, Continuous, Level and Pulse modes, plus manual triggering using the scan button.
- For outdoor integration, use suitable additional housing; IP54 does not mean waterproof or unrestricted exposed-weather use.
What Will Not Work
- A compatible host, integration software/setup and appropriate mounting design are required; host equipment and mounting accessories are not included.
- The 2 m USB extension cable is included; a serial cable and power adapter with interchangeable plugs are optional and not included.
- Plan for a wired USB or RS-232 host connection; RS-232 use requires the optional serial cable.
- The 60 frames-per-second imaging rate is not a guaranteed decoded-barcode rate, and supported examples do not guarantee every barcode or scanning condition.
- IP54 does not establish waterproofing, submersion protection or unconditional exposed outdoor use; additional suitable housing is required for outdoor integration.
- The Class 2 laser aimer carries an eye-safety caution; follow manufacturer instructions and avoid staring into the beam.
Key Features
Laser aimer
The exact NLS-FM430L-U variant uses a 650 nm Class 2 laser aimer; it is not the green-LED-only variant.
CMOS 1D/2D imaging
The 1280 × 800 imager supports paper and mobile-screen barcode reading, with examples including QR, PDF417 and EAN/UPC.
Adaptive illumination
White LED illumination works with light and IR sensors to adjust supplementary lighting for the application.
Flexible triggering
Sense, Continuous, Level and Pulse modes provide different scan behaviours, with manual triggering also supported.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
This exact laser-aimer version combines a 1280 × 800 CMOS imager, adaptive white illumination with light/IR sensors, and an included 2 m USB extension cable. The imaging rate is 60 frames per second, not a promise of 60 decoded barcodes per second.
Buyer’s Guide
✓ Buy it if For kiosk, POS and embedded-system integrators who need a fixed-mount 1D/2D reader with a laser aimer and USB extension. A compatible host, integration software and appropriate mounting design are required; host equipment and mounting accessories are not included.
✕ Skip it if This is a fixed-mount reader, not a handheld terminal, complete kiosk, payment system, RFID reader or printer. A compatible host, integration software/setup and appropriate mounting design are required; host/kiosk/display equipment and mounting accessories are not included. Do not assume a bundled payment app or software licence. The kit includes the reader and 2 m USB extension cable; a serial cable and power adapter with interchangeable plugs are optional and not included. Follow the manufacturer's instructions and avoid staring into the Class 2 aiming beam. IP54 is not waterproofing or approval for unprotected outdoor exposure; the manufacturer calls for suitable additional housing for outdoor integration. The 1.5 m drop rating is not a damage guarantee.
Features - Newland - NLS-FM430L-U
Colour
black
More Details
Product Code
CE77911
Manufacturer
Newland
