Microchip PD-9606GC/AC-EK 6-Port Managed Gigabit PoE Midspan, IEEE 802.3bt 90W per Port, 450W Budget, EU/UK Cord

Brand:
Microchip
Microchip PD-9606GC Six Port Managed PoE Midspan
Microchip PD-9606GC/AC-EK 6-Port Managed Gigabit PoE Midspan, IEEE 802.3bt 90W per Port, 450W Budget, EU/UK Cord
€1458.65 inc. VAT
Buy
PD-9606GC/AC-EK
€1,225.76
€1,458.65 inc. VAT
Ships from EU stock: 4 item(s)
+ −
Add to wish list Ask a question
Product Code
CJ96261
EAN Code
0844117003031
Manufacturer
Microchip

Quick Specs

PoE channels
6 × IEEE 802.3bt Type4; up to 90W per port
Total budget
450W shared across six ports
Data
10/100/1000Mbps Gigabit Ethernet
Management / power
PowerView Pro; 100–240VAC; EU/UK cord option
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

Add managed high-power PoE to an existing network

6 PoE channelsUp to 90W per port450W total budgetGigabit + PowerView Pro

The Microchip PD-9606GC/AC-EK is one managed indoor Gigabit PoE midspan that adds power to six Ethernet connections from an existing switch. Each channel can provide up to 90W using IEEE802.3bt Type4, with a shared 450W PoE budget across the unit. It is designed for compatible high-power access points, PTZ/dome cameras, IP phones, thin clients and similar powered devices. The AC-EK ordering option is identified by Microchip as EU/UK cord. You still need the network switch, compatible endpoints and Ethernet cabling.

Before you order:
Check both the PoE standard and power requirement of every endpoint, then add their simultaneous requirements against the 450W total. Six channels at 90W would require 540W and exceed this model budget. The 90W figure is the maximum source output per port, not a promise that every device receives 90W after cable losses. This is a midspan injector, not a replacement for the data-switching function of your Ethernet switch.

What's in the Box

  • 1 × PD-9606GC managed midspan
  • AC-EK EU/UK power-cord ordering option
  • PowerView Pro is included according to the manufacturer; network switch, powered endpoints and Ethernet cables are separate requirements

What It Means in Practice

  • For an access-point installation, connect an existing switch data port to a midspan channel input, connect the paired powered output to a compatible PoE endpoint and supply AC power to the midspan. Repeat for the required channels and check the power indicators.
  • Plan for different endpoint loads rather than multiplying six by the per-port headline. For example, the combined simultaneous requirement must remain within 450W even when each individual channel is below 90W.
  • PowerView Pro supports remote SNMP/web management and IPv4/IPv6 addressing. It helps manage the midspan from the network; the switch still handles network switching.
  • The 1U enclosure is 438 × 272 × 44mm and weighs 4.2kg. Allow suitable support, cabling and an indoor 0–40°C operating environment.

What Will Not Work

  • Six simultaneous 90W loads within this 450W unit budget.
  • Using the midspan alone as the data-switching network device.
  • Assuming passive PoE, arbitrary voltage devices or outdoor operation are supported by the IEEE indoor specification.

Key Features


Six high-power PoE channels
IEEE802.3bt Type4 provides up to 90W per port, with backward compatibility for IEEE802.3af/at powered devices and a 450W shared budget.

Retain the existing Gigabit network
10/100/1000Mbps data support lets the midspan add power between an existing switch and compatible Ethernet endpoints.

Managed power infrastructure
Included PowerView Pro supports secure remote SNMP/web-based management and IPv4/IPv6 addressing. AC and channel LEDs show power status.

Indoor 1U enclosure
A 438 × 272 × 44mm enclosure, shielded RJ45 connections and USB Type-B console/communication support a structured network installation.

Technical Specifications

Identity and PoE operation
Manufacturer / model Microchip PD-9606GC
MPN PD-9606GC/AC-EK
EAN 0844117003031
Product type Managed indoor PoE midspan injector
PoE channels 6
PoE standard IEEE 802.3bt Type4, 4-pair power
Per-port output Up to 90W
Total PoE power budget 450W shared; not 6 × 90W simultaneously
Backward compatibility IEEE 802.3af / 802.3at powered devices
Data rates 10/100/1000Mbps; 10/100Base-T and Gigabit devices
Installation Midspan between existing Ethernet switch and compatible powered devices
Power, interfaces and management
AC input 100–240VAC
Ordering suffix AC-EK: manufacturer EU/UK cord option
Management software PowerView Pro included; secure remote SNMP/web-based management
IP addressing IPv4 / IPv6
Ethernet connectors Shielded RJ45 for PoE channels and management; EIA568A / EIA568B
Console / communication USB Type-B
System indicator Green AC power LED
Channel indicators Green: power on data and spare pairs; orange: power on data or spare pairs
Physical and environmental
Dimensions 438 × 272 × 44 mm; 1U
Weight 4.2 kg
Operating temperature 0–40°C
Operating humidity 10–90%, non-condensing
Storage temperature −20–70°C
Storage humidity 5–95%, non-condensing
Operating altitude −304.8 to 2000 m
Compliance IEEE802.3bt, RoHS, CE
EMC / immunity FCC Part15 ClassB, EN55032 ClassB, EN55024, EN61000-3-2, EN61000-3-3, VCCI
Safety standards listed UL/EN/IEC60950-1; UL/EN/IEC62368-1

Frequently Asked Questions

Is the total PoE budget 540W?
No. The exact six-port model has a 450W shared PoE budget. Up to 90W is the individual-port maximum.
Can it replace my network switch?
No. It is a midspan that adds power to existing Ethernet data links. Connect it between the switch and compatible powered endpoints.
Will it power older PoE devices?
The manufacturer specifies backward compatibility with IEEE802.3af and IEEE802.3at powered devices. Check the endpoint standard and total load before installation.
Singular Expert Insight
This midspan is useful when the existing switch already meets data-network needs but the endpoints need more PoE power. Build a per-device power list first, then check the 450W total and IEEE compatibility. Do not select it from the 90W headline alone. Check endpoint PoE requirements with Singular

Buyer’s Guide

✓

Buy it if

 you need managed high-power PoE on six existing Gigabit data links within a 450W budget.
✕

Skip it if

 you need six simultaneous 90W outputs or a replacement Ethernet switch.
→

Also consider

 a PoE switch for a new network, or a different midspan power budget when endpoint totals require it.
Share endpoint model numbers and simultaneous power requirements for a PoE check.
