Five 80mm fans for simple DC-controlled airflow
5 Pack80mm3-pin
The ARCTIC P8 Silent ACFAN00301A is a five-pack of black 80mm fans with fluid dynamic bearings. Each fan is specified at 1600rpm at 12V and connects through a 3-pin lead; this is the Silent fixed-speed model, with speed adjustment available through suitable DC voltage control.
Compatibility — check before buying:
Check 80mm mounting positions with 25mm depth clearance and compatible 3-pin fan connections. PWM signals do not control this model: use a motherboard DC mode if voltage-based speed adjustment is required. Each fixed lead is 400mm long.
Best For
✓ Several verified 80mm mounting positions in a build.
✓ A system using suitable DC fan voltage control.
Key Features
Five matching fans
The ACFAN00301A package provides five P8 Silent fans. Check each mounting position and power connection before planning the complete installation.
Focused airflow
Each fan is specified at 15.6 CFM / 26.5m³/h and 0.62mm H₂O static pressure. Installed airflow depends on the resistance and layout of the equipment.
FDB and 3-pin connection
A fluid dynamic bearing supports each rotor. The 3-pin lead carries power and a tachometer signal; the motherboard PWM signal does not regulate the speed of this model.
Technical Specifications
What's in the Box
5 × P8 Silent fans
Frequently Asked Questions
Singular Expert Insight
The key buying distinction is 3-pin DC control. If your fan curve is designed specifically for 4-pin PWM or PST linking, compare the separately identified PWM PST version. Compare case fans by size and connection Tell us your case and motherboard models so we can check the requirements.
Buyer’s Guide
Buy it if
You need five matching 80mm fans and have suitable DC-compatible fan connections.
Skip it if
You require 4-pin PWM control, PST chaining or another mounting size.
Also consider
Compare the P8 PWM or PWM PST family when that control method is required.
Features - Arctic Cooling - ACFAN00301A
Colour
black
More Details
Product Code
03:243999
EAN Code
4895213704205
Manufacturer
Arctic Cooling
