ARCTIC P9 PWM PST 92mm Black Case Fan ACFAN00298A 3000 RPM 38.83 CFM
Brand:
Arctic Cooling
ACFAN00298A
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
ARCTIC P9 PWM PST — 92 mm High-Speed PWM Fan
200–3000 RPM38.83 CFM3.12 mmH₂OPWM PST
The ARCTIC P9 PWM PST (ACFAN00298A) is a black 92 mm fan designed for applications where compact dimensions, high rotational speed and useful static pressure are required. It operates from 200 to 3000 RPM under PWM control, can stop completely below 5% PWM, and delivers up to 38.83 CFM airflow with 3.12 mmH₂O static pressure.
Compatibility — check before buying:
This is a 92 × 92 × 25 mm 4-pin PWM fan with PST daisy-chain support. Confirm that your case, cooler or other mounting position accepts a 92 mm fan and that the intended header supports 12 V 4-pin PWM control. The integrated PST socket is intended for sharing the PWM control signal with another compatible fan.
Best For
✓ Compact PC cases with 92 mm fan mounts
✓ PWM-controlled intake or exhaust cooling
✓ Restricted airflow paths needing higher static pressure
✓ Multi-fan setups using ARCTIC PST daisy chaining
Key Features
200–3000 RPM PWM range
The P9 PWM PST operates from 200 to 3000 RPM under PWM control, allowing compatible hardware to balance cooling output against acoustic requirements.
0 RPM below 5% PWM
ARCTIC specifies complete fan stop below 5% PWM, enabling zero-RPM operation when the controlling motherboard or fan controller provides a sufficiently low PWM duty cycle.
3.12 mmH₂O static pressure
The fan is rated for 3.12 mmH₂O static pressure, making it suitable for installations where airflow must pass through more restrictive openings or cooling surfaces.
PST daisy-chain connection
Alongside its 4-pin fan plug, the P9 PWM PST includes a 4-pin socket and an 80 mm daisy-chain lead so another compatible PWM fan can share the control signal.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
The P9 PWM PST is more specialised than a basic 92 mm case fan. Its 3000 RPM maximum and 3.12 mmH₂O static-pressure rating make it useful where airflow resistance is higher, while PWM control lets the system reduce speed when that performance is not required. The integrated PST socket is especially useful in compact systems with limited motherboard fan headers because a second compatible PWM fan can share the control signal. Confirm the 92 mm mounting size before ordering, as it is physically smaller than the more common 120 mm format.
Buyer’s Guide
Buy it if
You need a high-speed 92 mm PWM fan with up to 3000 RPM, 3.12 mmH₂O static pressure and PST daisy-chain support.
Skip it if
Your system requires a 120 mm or 140 mm fan, or you do not have a suitable 4-pin PWM header or controller.
Check first
Verify a 92 mm mounting position with approximately 82.5 mm mounting-hole spacing and adequate clearance for the 25 mm fan thickness.
Features - Arctic Cooling - ACFAN00298A
More Details
Product Code
04:523244
EAN Code
4895213704939
Manufacturer
Arctic Cooling
