HPE Aruba CX 6100 24G PoE+ Managed Switch - 4SFP+
The HPE Aruba CX 6100 is a managed 28-port access switch for branch offices, SMBs and mid-market enterprise networks. It combines 24 Gigabit PoE+ copper ports with 4 1/10G SFP+ uplinks, plus an internal power supply and lifetime limited warranty.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Type | Switch - 28 ports - Managed |
| Ports | 24 x 10/100/1000 Base-T RJ-45 PoE+ | 4 x 1/10Gbit LAN SFP+ | 1 x USB-C console | 1 x USB Type A |
| PoE | PoE+ |
| PoE Budget | 370 W |
| Subtype | 10 Gigabit Ethernet |
| Switching Capacity | 128 Gbps |
| Throughput | 95.2 Mpps |
| Latency (1 Gbps) | 1.5 µs |
| Latency (10 Gbps) | 1.8 µs |
| MAC Address Table Size | 8192 entries |
| Processor | 1 x ARM A9: 1.016 GHz |
| RAM | 4 GB DDR3 SDRAM |
| Flash Memory | 16 GB |
| Power Device | Internal power supply |
| Power Provided | 500 Watt |
| Voltage Required | AC 100-127/200-240 V (50/60 Hz) |
| Power Consumption (Operational) | 22.9 Watt |
| Enclosure Type | Side to side airflow rack-mountable 1U |
| Width | 44.2 cm |
| Depth | 26.82 cm |
| Height | 4.39 cm |
| Weight | 4.19 kg |
| Service & Support | Limited warranty - lifetime |
| Authentication Method | Secure Shell (SSH), Secure Shell v.2 (SSH2), TACACS+, RADIUS |
| Encryption Algorithm | SSL |
| Features | DNS client, VLAN support, MSTP support, RSTP, LACP support, Energy Efficient Ethernet, flow control, TFTP support, ARP support, DHCP client, ICMP, SNTP support, BOOTP support, DiffServ support, IPv6 addressing, IPv6 support, LLDP support, LLDP-MED, MLD snooping, NDP, NAC, port based access control, sFlow, SNMP support |
| Compliant Standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3at, IEEE 802.3az, IEEE 802.3x |
| Routing Protocol | IGMPv2, IGMPv3 |
| Capacity | Switched virtual interfaces (SVIs): 16 | ARP entries: 1024 | IPv4 routes (Unicast): 512 | IPv6 routes (Unicast): 512 | IGMP groups: 512 | MLD groups: 512 | IPv4 ACL entries (ingress): 256 | IPv6 ACL entries (ingress): 128 | MAC ACL entries (ingress): 256 |
| Operating Temperature | 0 °C to 45 °C |
| Operating Humidity | 15 - 95% (non-condensing) |
| Storage Humidity | 15 - 90% (non-condensing) |
| Interfaces | 24 x 10/100/1000 Base-T RJ-45 PoE+ 4 x 1/10Gbit LAN SFP+ 1 x USB-C console 1 x USB Type A |
| Power | Internal power supply |
| Security | SSL |
| SKU / EAN | JL677A#ABB | 0190017348483 |
SINGULAR RECOMMENDS
For who
Suitable for branch offices, SMBs and mid-market enterprise networks that need managed PoE+ access switching with fibre uplinks.
Real reason to buy it
A practical Aruba CX access switch with 24 PoE+ ports, 4 SFP+ uplinks and a 370W PoE budget in a 1U rack-mountable design.
Know before
This is a managed switch with an internal power supply and 1U rack-mountable enclosure. The confirmed warranty is limited lifetime, and the listed operating range is 0 °C to 45 °C.
