ASRock B760 Pro RS ATX Motherboard LGA 1700 Intel B760 DDR5 PCIe 5.0 x16 Triple M.2 2.5GbE USB-C HDMI DP Black
Brand:
ASRock
ASRock B760 Pro RS ATX Motherboard LGA 1700 Intel B760 DDR5 PCIe 5.0 x16 Triple M.2 2.5GbE USB-C HDMI DP Black
€149.58 inc. VAT
90-MXBKS0-A0UAYZ
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
ASRock B760 Pro RS — Full-ATX LGA 1700 with PCIe 5.0
LGA 1700 · Intel B7604× DDR5 up to 7200+ MT/s OCPCIe 5.0 x16 + Triple M.2Dragon 2.5GbE · USB-C
The ASRock B760 Pro RS is a full-size ATX motherboard built on the Intel B760 chipset and the LGA 1700 socket, supporting 12th, 13th and 14th Generation Intel Core processors. Sold under ASRock part number 90-MXBKS0-A0UAYZ (EAN 4710483942044), it offers a PCIe 5.0 x16 graphics slot, four DDR5 slots (up to 256GB), three M.2 slots, four SATA ports, fast Dragon 2.5GbE networking and front/rear USB-C — a roomy, well-equipped base for mainstream and gaming builds. Typically in stock with fast delivery across Cyprus.
Compatibility — read before buying
This is an LGA 1700 board supporting 12th/13th/14th Gen Intel Core CPUs — it is not compatible with the newer LGA 1851 Core Ultra processors. This is the DDR5 version (no DDR4), with four DIMM slots (max 256GB). The PCIe 5.0 bandwidth applies to the x16 graphics slot; the three M.2 slots run at PCIe Gen4.
Best For
✓Mainstream and gaming LGA 1700 builds
✓Full-ATX cases with room for expansion
✓Triple-NVMe storage configurations
✓High-capacity DDR5 (up to 256GB)
✓Fast Dragon 2.5GbE networking
✓USB-C front and rear connectivity
Key Features
PCIe 5.0 x16 graphics slot
The primary x16 slot runs at PCIe 5.0, giving full bandwidth for current and next-generation graphics cards on an affordable B760 board.
Triple M.2 + 4× SATA
Three M.2 slots (two Hyper PCIe Gen4 x4, one Gen4 x2) and four SATA 6Gb/s ports provide excellent, fast storage flexibility.
Fast, high-capacity DDR5
Four DDR5 DIMM slots support up to 256GB and overclocked speeds of 7200+ MT/s, backed by a 10+1+1 power phase design.
Dragon 2.5GbE + USB-C
Realtek Dragon 2.5GbE LAN for fast networking, plus front and rear USB 3.2 Gen 2 Type-C and plentiful USB-A ports.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
The B760 Pro RS is a strong-value full-ATX board — a PCIe 5.0 x16 slot, triple M.2, four DDR5 slots, 2.5GbE and front/rear USB-C give it near-premium connectivity on a mid-range chipset, with Gen4 (not Gen5) M.2 the only trade-off. If you want built-in Wi-Fi, the B760 Pro RS WiFi 6E adds wireless; for the latest Core Ultra platform, an LGA 1851 B860 board is the move. Add a fast PCIe Gen4 internal SSD in a Hyper M.2 slot for best results.
Buyer's Guide
Buy it if
You want a roomy full-ATX LGA 1700 board with PCIe 5.0 graphics, triple M.2, four DDR5 slots, 2.5GbE and USB-C for gaming or productivity.
Skip it if
You want Gen5 M.2 storage, built-in Wi-Fi or the latest Core Ultra platform — choose a Wi-Fi variant or an LGA 1851 board.
Also consider
The ASRock B760 Pro RS WiFi 6E (Wi-Fi) or an LGA 1851 B860 board for the newer platform.
Features - ASRock - 90-MXBKS0-A0UAYZ
CPU Socket
- Socket 1700
Colour
black
Interface
- USB Type-C,
- USB3.1,
- M.2,
- Ethernet
More Details
Product Code
04:421746
EAN Code
4710483942044
Manufacturer
ASRock
