Digitus Fiber Optic Patch Cord OM3 LC/UPC to LC/UPC Duplex Multimode 50/125 LSZH 3m Aqua
Brand:
Digitus
Digitus Fiber Optic Patch Cord OM3 LC/UPC to LC/UPC Duplex Multimode 50/125 LSZH 3m Aqua
€7.9 inc. VAT
DK-2533-03/3
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Digitus OM3 LC to LC Duplex Fibre Patch Cord — 3 m
OM3 multimodeLC/UPC to LC/UPC3 m · AquaLSZH · Ø 2.0 mm
The Digitus DK-2533-03/3 is a 3 m duplex OM3 multimode fibre patch cord with LC on one end and LC on the other, for connecting multimode SR/SX transceivers, switches, media converters and patch panels. OM3 is laser-optimised 50/125 µm multimode for 850 nm short-reach optics (SR/SX transceivers) in the server room and between racks — the standard choice for 1G and 10G multimode links.
Both ends: LC — the small latching connector used by SFP, SFP+ and SFP28 transceivers and most modern patch panels.
What's in the Box
- 1 × DIGITUS OM3 multimode fibre patch cord, LC to LC, duplex, 3 m
- Individual test report — the cord is single-packed in a DIGITUS polybag (per datasheet)
What It Means in Practice
- Duplex means two fibres side by side, one transmit and one receive. The cord crosses Tx to Rx for you; if a link stays dark after patching, swap the two connectors on one end — it is the most common fibre patching mistake.
- 3 m is the right length rack to adjacent rack, or top to bottom of a cabinet. Order the shortest length that reaches without tension — excess fibre has to be coiled in the cable manager.
- Route the cord with gentle bends and keep it away from sharp edges and door hinges; fibre loses light when bent too tightly.
- LSZH jacket — low smoke, zero halogen — the expected choice for offices, server rooms and public buildings.
- Keep the dust caps on until the moment you plug in. A dirty ferrule is the number one cause of high loss; clean the end faces if the ports have been left open.
What Will Not Work
- Singlemode optics (LR, LX, ER, BiDi) — they need a 9/125 µm singlemode (OS2) cord; multimode fibre does not substitute.
- Patching into an existing 62.5/125 µm (OM1) installation — core sizes must match end to end.
- Ports with SC, ST, MTP/MPO connectors — this cord terminates in LC on both ends only.
- Green APC (8° angled) ports, as found on many FTTH/GPON terminals — this cord is UPC; you need an APC cord there.
- Copper RJ45 ports — fibre needs an SFP/fibre port or a media converter on each side.
Key Features
Connectors
LC on both ends, UPC polish.
Fibre grade
OM3 multimode, 50/125 µm.
Jacket
LSZH, 2.0 mm outer diameter, aqua — the colour code most installers expect for OM3.
Quality
Ceramic ferrules; every cord is single-packed in a Digitus polybag with its own individual test report, per the Digitus datasheet.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
Fibre patch cords are chosen by three things: the fibre grade (it must match the optics), the connector on each end and the polish. OM3 with LC to LC is the combination this cord covers. Need the active side as well? Browse our switches with SFP ports and match the transceiver to multimode fibre.
✓ Buy it if you need a 3 m OM3 multimode link with LC on both ends and UPC ports.
✕ Skip it if your optics are singlemode (LR/LX/BiDi), your ports are APC (green), or you need a different connector on either end.
→ Also consider the same Digitus OM3 cord in other lengths, or a OM3 LC to SC cord if one end of your link is different.
Not sure which grade or connector you have? Send us the model of your switch, transceiver or panel and we will check it before you order.
Features - Digitus - DK-2533-03/3
Colour
Cyan
Length
3m
More Details
Product Code
04:81140
EAN Code
4016032248873
Manufacturer
Digitus
