ASUS ASMB10-iKVM Server Remote Management Module IPMI 2.0 iKVM ASPEED AST2600 for ASUS Server Motherboards

Brand:
ASUS
90SC0HR0-M0UAY0
€41.94
€49.91 inc. VAT
Out of stock
Add to wish list Ask a question
Product Code
04:399913
EAN Code
4711081281689
Manufacturer
ASUS
Quick Specs
Type
Server BMC / iKVM module
Chipset
ASPEED AST2600
Interfaces
IPMI 2.0, Redfish, WebGUI
For
Supported ASUS server boards
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

ASUS ASMB10-iKVM - Server Remote Management Module

IPMI 2.0 + iKVMASPEED AST2600Out-of-Band ControlRedfish API

The ASUS ASMB10-iKVM (part number 90SC0HR0-M0UAY0) is a server remote-management module that adds full IPMI 2.0 and remote KVM (keyboard, video, mouse) control to compatible ASUS server motherboards. Built on the ASPEED AST2600 BMC with AMI MegaRAC SP-X firmware, it lets administrators monitor, power-cycle and troubleshoot a server over the network even when the operating system is down. Ideal for data centres, IT teams and remote-site servers. Typically in stock with fast delivery across Cyprus.

Compatibility
This is an upgrade module for ASUS server motherboards that provide the dedicated ASMB10 management header - it is not a standalone device and does not work in a standard desktop PC. Confirm your ASUS server board lists ASMB10-iKVM support before ordering. Management is accessed out-of-band over the network via WebGUI, IPMI or Redfish API.

Key Features


Remote iKVM Management
Full keyboard, video and mouse control over the network gives out-of-band access for around-the-clock monitoring and control, even if the server OS has failed.

IPMI 2.0 & Redfish
Manage hardware health, power and sensors through a web interface, standard IPMI 2.0 tools or the modern Redfish API, backed by the ASPEED AST2600 BMC.

Remote Update & Security
Supports remote BIOS and BMC firmware updates, HTML5 standalone KVM, and video recording with BSOD capture, with NIST SP 800-193-compliant firmware resiliency.

Technical Specifications

Identification
Part Number 90SC0HR0-M0UAY0
EAN / GTIN 4711081281689
MPN ASMB10-iKVM
Management
Type Server remote management module (BMC)
BMC Chipset ASPEED AST2600
Firmware AMI MegaRAC SP-X
Interfaces WebGUI, IPMI 2.0, Redfish API
Remote Presence iKVM (KVM over network)
Hardware & Features
Memory 448 MB RAM + 64 MB video + 64 MB ROM
Features 32-bit watchdog, native PCIe, secure boot engine
Update Remote BIOS/BMC/DFU, HTML5 KVM, BSOD video capture
Security PFR Root-of-Trust, NIST SP 800-193 compliant

Frequently Asked Questions

What does the ASMB10-iKVM do?
It adds out-of-band remote management to a supported ASUS server: administrators can monitor hardware, power the server on or off and take full keyboard/video/mouse control over the network through a web interface, IPMI or Redfish - even when the operating system is unresponsive.
Will the ASMB10-iKVM work in any PC?
No. It is an upgrade module for ASUS server motherboards that have the dedicated ASMB10 header. It is not a standalone card for desktop PCs, so check that your ASUS server board supports it.
Can I update firmware remotely with it?
Yes. It supports remote BIOS and BMC firmware updates, along with an HTML5 standalone KVM and video recording that captures a blue-screen (BSOD) for easier troubleshooting.
Singular Expert Insight
The ASMB10-iKVM turns a compatible ASUS server into a fully lights-out-manageable system: the AST2600 BMC, IPMI 2.0, Redfish and HTML5 iKVM cover everything a remote admin needs, and the PFR Root-of-Trust adds firmware security. It is a board-specific upgrade rather than a universal card, so its value is entirely tied to running it on a supported ASUS server motherboard - confirm compatibility first, then it pays for itself the first time you avoid an on-site visit.

Buyer's Guide

Buy it if
You run a compatible ASUS server board and need out-of-band IPMI 2.0 and remote iKVM management.
Skip it if
You have a desktop PC or a non-ASUS/unsupported server board.
Also consider
Check your ASUS server motherboard documentation for the exact ASMB10 compatibility.
