ASUS TUF Gaming B650M-E WIFI AM5 microATX Motherboard AMD B650 DDR5 PCIe 5.0 M.2 Wi-Fi 6 2.5Gb LAN Black
Brand:
ASUS
90MB1FV0-M0EAY0
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
ASUS TUF Gaming B650M-E WIFI AM5 micro-ATX Motherboard
Socket AM5DDR5 up to 192GBPCIe 5.0 M.2Wi-Fi 6
The ASUS TUF Gaming B650M-E WIFI is a micro-ATX AMD B650 motherboard on Socket AM5, built for durable, well-rounded gaming and productivity builds using AMD Ryzen 9000, 8000 and 7000 series processors. Identified by part number 90MB1FV0-M0EAY0 (EAN 4711387222041), it combines four DDR5 slots up to 192GB, a PCIe 5.0-capable M.2 slot with heatsink, Wi-Fi 6 and 2.5Gb Ethernet in a compact form factor. Typically in stock with fast delivery across Cyprus.
Compatibility — read before buying
This is a Socket AM5 board and requires an AMD Ryzen 7000/8000/9000 desktop CPU (sold separately) and DDR5 memory — DDR4 and AM4 CPUs are not compatible. The DisplayPort/HDMI video outputs work only with a Ryzen CPU that has integrated graphics (or use a discrete graphics card). The M.2_1 slot runs at PCIe 5.0 x4 with Ryzen 9000/7000 CPUs. BIOS FlashBack lets you update the firmware for the newest CPUs without a processor installed.
Best For
✓ Compact micro-ATX AMD Ryzen gaming builds
✓ DDR5 systems needing high memory capacity
✓ Fast PCIe 5.0 NVMe SSD storage
✓ Wireless builds needing Wi-Fi 6 + 2.5Gb LAN
✓ Future upgrades across Ryzen 7000–9000
✓ Reliable TUF-grade durability on a budget
Key Features
Socket AM5 · AMD B650
Supports AMD Ryzen 9000, 8000 and 7000 series desktop CPUs on the modern AM5 platform, giving a clear upgrade path across three generations of processors.
DDR5 up to 192GB
Four DIMM slots run dual-channel DDR5 up to 192GB with AMD EXPO one-click overclocking and rated speeds of DDR5-7600+ (OC) for high-bandwidth gaming and content work.
PCIe 5.0 M.2 + Dual M.2
Two M.2 slots (M.2_1 up to PCIe 5.0 x4 with Ryzen 9000/7000) plus four SATA 6Gb/s ports and a pre-mounted M.2 heatsink keep fast NVMe drives cool.
Wi-Fi 6 + 2.5Gb LAN
Onboard Wi-Fi 6 (802.11ax) with Bluetooth 5.2 and Realtek 2.5Gb Ethernet with TUF LANGuard deliver fast, stable wired and wireless connectivity.
8+2 DrMOS Power
A DIGI+ VRM with 8+2 DrMOS power stages and ProCool connectors provides stable, cool power delivery for demanding multi-core Ryzen processors.
TUF Protection & EZ DIY
SafeSlot Core+, ESD Guards, BIOS FlashBack, M.2 Q-Latch and Q-LED diagnostics make building and maintaining the system easier and more reliable.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
The B650M-E WIFI is the value pick in ASUS TUF micro-ATX AM5 range: it keeps the essentials — PCIe 5.0 M.2, DDR5, Wi-Fi 6, 2.5Gb LAN and a robust 8+2 DrMOS VRM — while trimming the extra M.2 slots and USB4 you would find on pricier B650 or X670 boards. If you plan heavy multi-GPU-class storage or need a PCIe 5.0 graphics slot, step up to a B650(E) model; for most single-GPU Ryzen gaming builds this is plenty. Complete the build with a compatible graphics card and a matched power supply.
Buyer’s Guide
Buy it if
You want a compact, durable AM5 board for a Ryzen 7000–9000 build with DDR5, PCIe 5.0 M.2 and Wi-Fi 6 at a sensible price.
Skip it if
You need three or more M.2 slots, a PCIe 5.0 x16 graphics slot, USB4, or a full-size ATX layout with more expansion.
Also consider
A B650E or X670E board for PCIe 5.0 graphics and extra M.2, or an ATX B650 model if you have room and want more headers.
Features - ASUS - 90MB1FV0-M0EAY0
CPU Socket
- Socket AM5
Colour
black
More Details
Product Code
04:432976
EAN Code
4711387222041
Manufacturer
ASUS
