Avision AD345GFN A4 Legal Flatbed Duplex Network Scanner 60ppm
Brand:
Avision
000-1013-02G
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Shared network scanning with duplex ADF and Legal flatbed
60ppm / 120ipm at 200dpi100-sheet duplex ADFLegal flatbedGigabit Ethernet + USB 3.2
The Avision AD345GFN combines automatic duplex document feeding, Legal flatbed capture and wired network sharing. Its 100-sheet ADF reaches up to 60ppm/120ipm for colour A4 at 200dpi, or 45ppm/90ipm for colour A4 at 300dpi. Optical resolution is 600dpi through the ADF and 1200dpi on the flatbed. Gigabit Ethernet and USB 3.2 Gen 1 connect it to supported office computer workflows.
Best For: Teams sharing a document scanner and handling both prepared sheet batches and suitable originals that need flatbed glass.
Before you order: Install compatible drivers and configure the manufacturer network-sharing software, such as Virtual Scanner Link, on supported computers. Email and cloud destinations depend on host applications, accounts and service compatibility. This GFN model has wired networking; Wi-Fi belongs to the separate GFWN variant. Release the flatbed transport lock before use and allow room for extended trays.
What's in the Box
- Avision AD345GFN scanner.
- USB cable, external power adapter and power cord.
- Quick guide and manufacturer driver/software resources.
- The linked family manual also lists an Ethernet cable and calibration sheet; check regional carton contents.
- Computer, network equipment and sample originals are separate.
What It Means in Practice
- Share capture across a configured compatible network using the supported driver and Virtual Scanner Link workflow.
- Use the 100-sheet ADF at its 80g/m² capacity condition for prepared suitable batches.
- Use flatbed glass for originals unsuitable for the feeder and choose the resolution for the task.
- Select the correct curved or straight paper path and media settings for supported originals.
What Will Not Work
- No Wi-Fi is specified for the exact AD345GFN; do not transfer GFWN features.
- This computer-shared network scanner is not a standalone touchscreen scan station.
- Colour speed at 300dpi is 45ppm/90ipm, not the 200dpi rating.
- Physical paper support up to 242mm does not enlarge the 216mm optical capture width.
- Current software, cloud destinations and operating-system support must be checked separately.
Key Features
Wired network sharing
Gigabit Ethernet and the supported network driver/software allow compatible computers to share capture.
Duplex batch capture
A 100-sheet feeder reaches 60ppm/120ipm for colour A4 at 200dpi.
Integrated flatbed
Legal glass supports suitable delicate or irregular originals with 1200dpi optical capture.
Flexible paper handling
Reverse roller, straight/curved paths, ultrasonic multifeed detection and skew protection support document preparation.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
Agree on the computer and network capture workflow before deploying the scanner. Test permissions, driver access and representative documents, then choose ADF or flatbed per original. Resolution affects colour speed, so use a profile that fits the output requirement rather than copying a single headline rating.
Buyer’s Guide
✓ Buy it if You need shared wired-network duplex capture plus integrated Legal flatbed glass.
✕ Skip it if You need Wi-Fi, standalone touchscreen destinations or a portable battery-powered scanner.
→ Also consider Supported network software, permissions, extended desk footprint and media handling.
Features - Avision - 000-1013-02G
Colour
white
Interface
- USB3.2,
- Ethernet
More Details
Product Code
04:415829
EAN Code
4713494651929
Manufacturer
Avision
