Axis M3086-V 02374-001 Indoor Mini Dome IP Camera 4MP 130° Wide View Lightfinder Forensic WDR PoE IK08 Deep Learning White

Brand:
AXIS
Axis M3086-V 4MP Indoor Mini Dome Camera, 130° View
Axis M3086-V 02374-001 Indoor Mini Dome IP Camera 4MP 130° Wide View Lightfinder Forensic WDR PoE IK08 Deep Learning White
€628.92 inc. VAT
Buy
02374-001
€528.50
€628.92 inc. VAT
Ships from EU stock: 78 item(s)
+ −
Add to wish list Ask a question
Product Code
CE93895
EAN Code
7331021076648
Manufacturer
AXIS

Quick Specs

Resolution
4MP 2688 x 1512
Lens / View
2.4 mm, 130° H
Low Light
Lightfinder, WDR 120 dB
Power / Rating
PoE Class 2, IP42, IK08
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

Axis M3086-V 4MP Indoor Mini Dome Camera

4MP 2688 x 1512130° extra-wide viewDeep-learning analyticsIK08 mini dome

The Axis M3086-V (part number 02374-001) is a 4MP indoor mini dome that covers a whole room from a corner. Its 1/2.7" sensor and 2.4 mm lens record 2688 x 1512 over a 130° horizontal view, Lightfinder keeps colour in low light and Forensic WDR up to 120 dB copes with windows. AXIS Object Analytics classifies people and vehicles on the camera, and Axis Edge Vault with a CC EAL6+ secure element protects the device. It draws 4.2 W over PoE, is IK08 rated and weighs 150 g. This part number has no microphone.

Compatibility — check before buying:
In the box: Camera and installation guide. Not in the box: microSD card, PoE switch or injector, network cable, AXIS TM3812 tamper cover, black casing, smoked dome, AXIS T61 audio interface (optional). Indoor only: IP42 and 0 °C to 45 °C; it is not for outdoor walls. No microphone: audio needs an Axis portcast accessory (AXIS T61 series); the M3086-V Mic (02832-001) has one built in. No IR: it relies on Lightfinder for low light and needs some ambient light at night. Tell us your recorder or video software and we check it for you.

Best For

✓ Offices and meeting rooms
✓ Shops and tills
✓ Hotel corridors
✓ Classrooms
✓ Receptions
✓ Clinics and waiting rooms

Key Features


4MP, extra wide
2.4 mm lens with a 130° horizontal view for whole-room coverage.

Colour in low light
Lightfinder and Forensic WDR up to 120 dB.

Analytics on the edge
AXIS Object Analytics, Scene Metadata, Live Privacy Shield and Audio Analytics support.

Secure by design
Axis Edge Vault with CC EAL6+ secure element and secure boot.

Technical Specifications

Identification
Brand Axis Communications
Model AXIS M3086-V Dome Camera
Part Number 02374-001
EAN / GTIN 7331021076648
Product Type Indoor mini dome camera
Image & Lens
Sensor 1/2.7" RGB CMOS
Resolution 2688 x 1512 (4MP), 25/30 fps
Lens 2.4 mm, F2.1
Field of View H 130°, V 93°
Low Light
Lightfinder Yes
WDR Forensic WDR, up to 120 dB
Min. Illumination Colour 0.19 lux, B/W 0.03 lux
IR None
Analytics
Included AXIS Object Analytics, AXIS Scene Metadata, AXIS Live Privacy Shield, AXIS Video Motion Detection, active tampering alarm, audio detection, AXIS Audio Analytics (needs an audio source)
Network & Power
Network 10/100 Mbps RJ45
Power PoE IEEE 802.3af/at Type 1 Class 2, typical 3.6 W, max. 4.2 W
Storage microSD/SDHC/SDXC slot (card not included)
Security Axis Edge Vault, signed OS, secure boot
Audio
Built-in Microphone No
Audio I/O Via portcast (AXIS T61 series, optional)
Physical
Rating IP42, IK08 (indoor)
Casing Polycarbonate/ABS, white NCS S 1002-B, repaintable
Weight 150 g
Operating Conditions 0 °C to 45 °C, 10–85% RH non-condensing
In the Box
Included Camera and installation guide
Not included microSD card, PoE switch or injector, network cable, AXIS TM3812 tamper cover, black casing, smoked dome, AXIS T61 audio interface (optional)
Warranty
Warranty 1-Year Warranty (Singular)
Manufacturer Term Axis publishes a 5-year warranty on this product. Singular’s direct warranty is 1 year; beyond that we assist you with the manufacturer’s warranty process for its full duration.

Frequently Asked Questions

Where does it record?
To a microSD card in the camera (not included; see our microSD cards), to a network recorder, or to video management software such as AXIS Camera Station. Tell us your current recorder or software and we check compatibility.
How is it powered?
Over PoE (IEEE 802.3af/at Type 1 Class 2), maximum 4.2 W, so any standard PoE switch port or injector works. Neither is included; see our PoE switches.
Does this model have a microphone?
No. Part number 02374-001 is the standard M3086-V without a microphone. The M3086-V Mic is a separate part, 02832-001. Audio on this model is possible only with an Axis portcast accessory.
Can I mount it outside?
No. It is rated IP42 and 0 °C to 45 °C, for indoor ceilings and walls. For outdoor use look at an IP66 model such as the AXIS M2035-LE bullet.
Singular Expert Insight
The M3086-V is the wide-angle choice in Axis’s mini dome range: 4MP and 130° let one camera cover a room that would need two narrower ones. For a smaller space the 2MP M3085-V costs less; for 4K detail the M3088-V. Browse all our IP cameras and add a microSD card from our microSD cards.

Buyer’s Guide

Buy it if

You want one discreet indoor camera to cover a whole room in 4MP.

Skip it if

You need a microphone (order 02832-001), outdoor mounting or IR.

Also consider

AXIS M3086-V Mic (02832-001); AXIS M3085-V (02373-001) for 2MP. See all IP cameras.
