HPE Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter, 4x RJ45, OCP 3.0 Form Factor, PCIe Gen2
Brand:
Hewlett Packard
HPE Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter, 4x RJ45, OCP 3.0 Form Factor, PCIe Gen2
€128.04 inc. VAT
P51181-B21
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
4x 1GbE RJ45OCP 3.0HPE optionBroadcom BCM5719
The Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE (P51181-B21) is a quad-port Gigabit Ethernet card in the OCP 3.0 form factor, for HPE servers that have an OCP 3.0 slot for their primary network adapter.
Using the OCP slot for the network card keeps every standard PCIe slot free for storage controllers, GPUs or faster NICs, while giving the server four copper Gigabit ports on HPE-qualified Broadcom silicon.
Before you order: This card only fits an OCP 3.0 slot. It will not go into a standard PCIe slot — for that, order P51178-B21, the PCIe stand-up version of the same adapter. Not every HPE server has an OCP 3.0 slot; send us your server model and we will confirm.
What's in the Box
- 1x Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
- No network cables or driver media — firmware and drivers come from HPE's Service Pack for ProLiant or the OS
What It Means in Practice
- Four Gigabit ports from the OCP slot, with every PCIe slot still free for other cards.
- Suitable as the server's main LAN: management, VM and backup traffic on separate ports, or teamed for redundancy.
- Standard Cat5e or better patch cables to any Gigabit switch — no transceivers required.
- UEFI and legacy PXE boot and Wake-on-LAN for deployment and remote power-on.
What Will Not Work
- It will not fit a standard PCIe slot — use P51178-B21 for that.
- It will not fit servers that have only a FlexibleLOM connector or no OCP 3.0 slot at all.
- It will not run 2.5GbE, 10GbE or faster, and it has no SFP ports for fibre.
- Non-HPE servers are not an HPE-supported configuration.
Key Features
OCP 3.0 form factor
Uses the dedicated OCP slot, so the network card does not take a PCIe slot.
HPE qualified
Firmware and drivers delivered through HPE tooling for supported servers.
Boot and wake
UEFI and legacy BIOS PXE boot plus Wake-on-LAN.
Offloads
TSO, RSS and checksum offloads reduce CPU load.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
If your HPE server has an OCP 3.0 slot, putting the Gigabit ports there is the tidiest design: four copper ports without spending a PCIe slot. The only real risk is ordering the wrong form factor, so check the slot first. We can also supply the matching Gigabit switches for the other end of the links.
✓ Buy it if your HPE server has a free OCP 3.0 slot and you need four copper Gigabit ports.
✕ Skip it if you only have standard PCIe slots, or you need 10GbE or fibre.
→ Also consider P51178-B21, the PCIe stand-up version of the same adapter.
Not sure which slot your server has? Send us the model and configuration and we will confirm before you order.
Features - Hewlett Packard - P51181-B21
Interface
- Ethernet
More Details
Product Code
CF23424
EAN Code
0190017576114
Manufacturer
Hewlett Packard
