Cambium Networks cnMatrix EX2028 Managed L2/L3 Switch
The Cambium Networks cnMatrix EX2028 is a managed 28-port switch for wired network deployments that need Gigabit access ports, SFP uplinks and central management. It is rack-mountable in 1U, fanless, and supports cloud-based management alongside web and CLI access.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Type | Switch - 28 ports - Managed |
| Switch Layer | L2/L3 |
| Enclosure Type | Rack-mountable 1U |
| Ports | 24 x 10/100/1000 + 4 x SFP (mini-GBIC) (uplink) |
| Interfaces | 24 x Gigabit LAN RJ-45 | 4 x Gigabit LAN SFP uplink | 1 x serial (console) | 1 x USB | 1 x management | 24 x Gigabit LAN RJ-45 ¦ 4 x Gigabit LAN SFP uplink ¦ 1 x serial (console) ¦ 1 x USB ¦ 1 x management |
| Switching Capacity | 128 Gbit/s |
| Forwarding Rate | 120 Mpps |
| Throughput | 84 Gbps |
| MAC Address Table | 16K entries |
| VLAN Support | Yes |
| Number of VLANs | 4000 |
| QoS Queues | 8 |
| ACL Entries | 128 |
| Static ARP Entries | 512 |
| ARP Entries | 512 |
| Static Routes | 64 |
| Dynamic Routes | 512 |
| IGMP Multicast Groups | 256 |
| Jumbo Frame Support | Yes |
| Jumbo Frames | 9000 |
| Management Protocols | SNMP 1, SNMP 2, SNMP 3, Telnet, HTTP, HTTPS, TFTP, CLI |
| Remote Management | Web-based management | Cloud-managed |
| Security | 802.1x RADIUS | SSH | SSH-2 | SSL/TLS |
| Authentication | Port-based authentication | IEEE 802.1x |
| DHCP Features | DHCP client | DHCP relay | DHCP server | DHCP snooping |
| Features | Auto-uplink (auto MDI/MDI-X) | IGMP snooping | Port mirroring | DiffServ support | Broadcast storm control | Multicast storm control | Unicast storm control | SNTP support | PVST | QoS | Reset button | Fanless | LLDP support | Port isolation | IGMP proxy | Link Aggregation | Root Guard | PVE | LLDP-MED | IGMP fast leave | DoS protection | BPDU Filter | Telnet server | Telnet client | BPDU Guard |
| Networking Standards | IEEE 802.3 | IEEE 802.3u | IEEE 802.1D | IEEE 802.1Q | IEEE 802.1p | IEEE 802.3x | IEEE 802.3ad (LACP) | IEEE 802.1w | IEEE 802.1x | IEEE 802.3ac | IEEE 802.1s | IEEE 802.1ak |
| Processor | 800 MHz |
| Memory | 512 MB RAM |
| Flash Memory | 128 MB |
| Power | Internal power supply |
| AC Input Voltage | 100 - 240 V |
| Power Consumption (Typical) | 19.5 W |
| Power Consumption Operational | 19.5 Watt |
| Power Supply Included | Yes |
| Rack Mounting Kit | Included |
| Status Indicators | Link/activity |
| Dimensions | 440 x 209 x 44 mm |
| Weight | 2.77 kg |
| Colour | Not specified |
| Minimum Operating Temperature | 0 °C |
| Maximum Operating Temperature | 50 °C |
| Operating Humidity | 55 - 95% |
| Manufacturer SKU | MX-EX2028XXA-E |
| EAN/UPC | 5706998582928 |
| Management Protocol | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, TFTP, CLI |
| SKU / EAN | MX-EX2028XXA-E | 5706998582928 |
SINGULAR RECOMMENDS
For who
Suitable for organisations that need a managed rack-mount switch with Gigabit access, SFP uplinks and centralised control.
Real reason to buy it
A practical 28-port managed switch with cloud management, strong security options and a fanless 1U design for structured network deployments.
Know before
This model does not support PoE. The input data lists cloud, web and CLI management, but no bundled transceivers or accessories beyond the included rack mounting kit.
