Cisco QSFP-100G-DR-S= QSFP28 Transceiver 100GBASE-DR Single Lambda Duplex LC Single-Mode up to 500 m

Brand:
Cisco
Cisco QSFP-100G-DR-S= QSFP28 Transceiver Module 100GbE 100GBase-DR
Cisco QSFP-100G-DR-S= QSFP28 Transceiver 100GBASE-DR Single Lambda Duplex LC Single-Mode up to 500 m
€2119.56 inc. VAT
Buy
QSFP-100G-DR-S=
€1,781.14
€2,119.56 inc. VAT
Ships from EU stock: 39 item(s)
+ −
Add to wish list Ask a question
Product Code
677UY70
EAN Code
0889728340434
Manufacturer
Cisco

Quick Specs

Standard
100GBASE-DR · 100 Gbps
Fibre & Reach
Single-mode · up to 500 m
Connector
Duplex LC
400G Interop
400G-DR4 via breakout
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

Cisco QSFP-100G-DR-S= — 100G DR Single-Lambda, 500 m

100 GbpsSingle-mode 500 mDuplex LC400G-DR4 ready

The Cisco QSFP-100G-DR-S= is a 100GBASE-DR QSFP28 transceiver that carries 100 Gbps on one wavelength over a duplex LC single-mode pair, up to 500 m. It is designed for data-centre links, and Cisco states it interoperates with 400GBASE-DR4 modules such as the QSFP-400G-DR4-S through fibre breakout cables — so a 400G spine can feed four 100G leaf switches. In practice, single-mode optics are the choice when a link leaves the building or runs several hundred metres: the OS2 fibre used by carriers and campus backbones carries the signal for kilometres with little loss. Before you order, confirm the fibre is single-mode at both ends and note the length and the number of patch panels on the way.

Compatibility — check before buying:
Reach is 500 m. It will not link to LR4, CWDM4 or SM-SR modules — the far end must be DR, or a 400G-DR4 lane via breakout. For longer single-mode runs the QSFP-100G-FR-S= uses the same connector and wavelength but reaches 2 km. Cisco marks this module with an orange pull tab. Keep the dust cap on until you connect the fibre, and clean both connector ends before every mating — dirt is the most common cause of a link that will not come up. Not sure? Send us your switch model and the cable run and we check it before you order.

Best For

✓ 100G leaf links from a 400G-DR4 spine
✓ Data-centre runs up to 500 m on single-mode
✓ Single-mode cabling inside the data hall
✓ Cisco Nexus QSFP28 ports
✓ Future-proofing for 400G
✓ Replacing a failed DR module

Key Features


Talks to 400G
Cisco lists interoperability with 400GBASE-DR4 modules via fibre breakout cables, so this module fits directly into a 400G single-lambda design.

Single-mode fibre, long reach
Built for single-mode (OS1/OS2) fibre, the type used between buildings, floors and sites. It will not run over the orange or aqua multimode fibre found in many racks — the fibre type has to match at both ends.

Hot-swappable
Modules plug into a live port without shutting the switch down, so a link can be added or replaced during working hours. Seat it until it clicks and use the latch to remove it.

Plan both ends together
A link only comes up when both ends use the same standard, speed and media. Order the far-end optic, the patch cord and any spares in one go and the link works on day one.

Technical Specifications

Identification
Brand Cisco
Model QSFP-100G-DR-S (100GBASE-DR QSFP Transceiver)
Part Number QSFP-100G-DR-S=
EAN / GTIN 0889728340434
Pack Size Single unit
Interface
Form Factor QSFP28
Standard 100GBASE-DR (single wavelength)
Data Rate 100 Gbps
Connector Duplex LC
Optics & Reach
Wavelength 1304.5–1317.5 nm, single lambda
Fibre Single-mode G.652
Reach Up to 500 m
Tx Power −2.9 to +4 dBm
Rx Power −5.9 to +4 dBm
Environment & Power
Operating Temperature 0 to 70 °C
Modulation PAM4 with onboard FEC
Power Consumption 4.3 W
Pull Tab Colour Orange
Compatibility
Designed For Cisco switches and routers whose port and software release are listed for this module in Cisco’s Transceiver Module Group (TMG) compatibility matrix
Link Partner Another 100GBASE-DR module, or one lane of a 400GBASE-DR4 module (such as QSFP-400G-DR4-S) via a breakout cable
In the Box
Included 1 module
Not Included Fibre patch cords and cleaning tools
Warranty
Warranty 1-Year Warranty (Singular)
Manufacturer Term Cisco publishes a standard warranty of 5 years in the data sheet for this module; expedited replacement needs a Cisco SMARTnet contract. Singular’s direct warranty is 1 year; beyond that we assist you with the manufacturer’s warranty process for its full duration.

Frequently Asked Questions

Can it connect to a 400G port?
Yes, to one lane of a 400GBASE-DR4 module such as Cisco’s QSFP-400G-DR4-S, through a fibre breakout cable. Cisco states this interoperability in its data sheet.
DR or FR — which do I need?
Both use one wavelength on duplex LC. DR reaches 500 m, FR reaches 2 km. For runs inside one data hall DR is enough.
Are fibre patch cords included?
No. You get 1 module. The Duplex LC patch cord, a matching module for the far end of the link and a fibre cleaning tool are bought separately. Tell us the distance and the fibre type and we quote the right cord.
Will it work in a switch from another brand?
Cisco modules carry Cisco Quality ID coding, and Cisco’s installation notes say to use only Cisco transceivers in Cisco devices. Support is confirmed per host model and software release in the Cisco TMG matrix. Cisco does not publish operation in other brands’ switches, so we do not promise it — send us the model and we check it.
Singular Expert Insight
We recommend DR optics for single-mode data halls that are planning for 400G: the same fibre plant and connector carry 100G today and connect to 400G-DR4 later. If any run is over 500 m, choose the QSFP-100G-FR-S= instead. Every order is backed by Singular’s local support in Cyprus — if a link will not come up, send us the port status from the switch and we help you find out whether it is the optic, the cable or the configuration. Browse all transceivers and DAC cables or the switches they plug into.

Buyer’s Guide

Buy it if

You need 100G links up to 500 m on single-mode fibre, or 100G lanes from a 400G-DR4 spine.

Skip it if

Your run exceeds 500 m, or the far end is LR4, CWDM4 or SM-SR.

Also consider

Cisco QSFP-100G-FR-S= for 2 km.
