Cisco 19-Inch Rack Mount Accessory Kit for Catalyst 9500 High Performance Switches, Brackets, Cable Guide, Screws, Ground Lug

The Cisco C9500-ACCKITH-19I= is the 19-inch rack mount accessory kit for Catalyst 9500 High Performance switches — C9500-32C, C9500-32QC, C9500-48Y4C, C9500-24Y4C — with the two mounting brackets, cable guide, screws and ground lug needed to install the switch in a standard 19-inch rack.

Its contents are the same as the kit that ships with the switch, so it is the part to order when the original kit is missing, when a switch is moved to a new rack, or when you are building up a spare-parts stock. The brackets can be fitted in a front, middle or rear position on the chassis.

• 2 × 19-inch mounting brackets
• 1 × cable guide
• 4 × Number-12 pan-head 0.50 in screws
• 1 × M4.0 x 20 mm Phillips pan-head screw (black), for the cable guide
• 12 × M4.0 x 6 mm Phillips flat-head screws, bracket to chassis
• 4 × Number-10 pan-head 0.625 in screws
• 1 × ground lug
• 2 × M4.0 x 8 mm Phillips pan-head screws, for the ground lug

• Replaces a lost or incomplete original kit, so a Catalyst 9500 can be racked without waiting for a full chassis accessory shipment.
• Front, middle or rear bracket positions let you align the switch with patch panels or recess it in the rack.
• The ground lug and its screws are included for proper chassis grounding.
• Four-point mounting (for example for NEBS installations) needs Cisco C9500-4PTH-KIT= in addition.

• Catalyst 9500 standard models (C9500-12Q, C9500-24Q, C9500-40X and C9500-16X) — use C9500-ACC-KIT-19I= instead.
• 23-inch racks — use C9500-ACCKITH-23I=.
• Four-point mounting on front and rear rails on its own — that needs C9500-4PTH-KIT=.
• Catalyst 9500X models — Cisco does not state compatibility for this kit.
