Cisco Catalyst 1300X-48NGU-4X 48-Port L3 Managed Stackable Gigabit Ethernet Switch
The Cisco Catalyst 1300X-48NGU-4X is a 48-port L3 managed, stackable Gigabit Ethernet switch for rack-mount networking. It combines PoE++ and PoE+ access ports, 10G SFP28 uplinks, and a 740W PoE budget, making it a practical choice for networks that need flexible connectivity and central management.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Type | Switch - 48 ports - L3 - Managed - stackable |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Interfaces | 40 x 10/100/1000 Base-T (PoE+) RJ-45 PoE+ - 30 W | 8 x 100/1000/2.5G/5GBase-T RJ-45 PoE++ - 60 W | 4 x 10GBase-X SFP28 uplink | 1 x console RJ-45 | 1 x USB-C console |
| Power Over Ethernet (PoE) | PoE++ |
| PoE Budget | 740 W |
| Performance | Forwarding rate (64-byte packets): 178.57 Mpps | Switching capacity: 240 Gbps |
| Capacity | MSTP instances: 16 | RPVST+ instances: 126 | Link aggregation groups: 8 | Link aggregation ports: 16 | VLAN entries: 4094 | IGMP multicast groups: 4000 | IPv4 routes: 7168 | IPv4 interfaces: 256 | ACL rules: 3072 | Priority queues: 8 | Packet buffer size: 8 MB | Link aggregation groups: up to 8 | Link aggregation ports per channel: up to 8 |
| MAC Address Table Size | 32000 entries |
| Jumbo Frame Support | 9000 bytes |
| Max Units In A Stack | 8 |
| Routing Protocol | STP, static IP routing, RSTP, MSTP, IGMP, IGMPv2, IGMPv3, CIDR, RIP-2, policy-based routing (PBR), MLD, MLDv2, OSPF, RIP, OSPFv2, OSPFv3 |
| Remote Management Protocol | CLI, SNMP, Telnet, SSH, SSH-2, DHCP, SCP, HTTPS, HTTP, ICMP, TFTP, Syslog, SNMP 2c, SNMP 3, RMON |
| Encryption Algorithm | MD5, SSL |
| Authentication Method | RADIUS, TACACS+, Secure Shell (SSH), Secure Shell v.2 (SSH2) |
| Features | VLAN support, STP support, CLI management, ATP, FHS, QoS, sFlow, dynamic routing, Zero-Touch Deployment, Port Security, Web authentication, Address Resolution Protocol, ARP inspection, IP source guard, DHCP snooping, IPMB, NDP, router advertisement guard, DHCPv6 guard, layer 3 routing, LAG, port mirroring, eco-friendly button, EEE, RSTP, MSTP support, PVST+, RPVST+, LACP, Protocol-based VLANs support, MAC based VLAN, VLAN management, Private VLAN, PVE, Guest VLAN, GVRP, CPE VLAN, Auto Surveillance VLAN, MVR, Q-in-Q tunnelling, TPID, GARP, UDLD, DHCP relay, DHCP server, IGMP snooping, IGMP querier, IGMP proxy, HoL Blocking Prevention, loopback detection, ACL support, BOOTP support, UDP, High Availability, MAC address authentication, BPDU Guard, STP Root Guard, STP loop guard, DAI, DoS protection, SCT, SSD, trustworthy systems, Broadcast Storm Control, Multicast Storm Control, Storm Control, Unicast Storm Control, Unknown Storm Control, DoS attack prevention, WRR, ToS, DSCP based CoS, DiffServ support, TCP congestion, iSCSI traffic optimisation, path MTU discovery, DAD, RA guard, MLD snooping, MLD proxy, Telnet server, DNS client, Telnet client, DHCP client, Cisco NG PnP Protocol, IPv4 and IPv6 dual stack, VLAN mirroring, RSPAN, SCP, chip guard, boot integrity, time-based port operation, cable length detection, LLDP, LLDP-MED, reset button, persistent PoE, SSD |
| Compliant Standards | IEEE 802.1p, IEEE 802.1x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1ab (LLDP), IEEE 802.3, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z |
| Processor | X ARM: 1.5 GHz |
| RAM | 2 GB DDR4 SDRAM |
| Flash Memory | 1 GB |
| Built-in Devices | 2 x fans |
| Status Indicators | System, link/activity/speed, PoE |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V (50 - 60 Hz) |
| Included Accessories | Pointer card, mounting kit |
| Width | 44.43 cm |
| Depth | 34 cm |
| Height | 4.394 cm |
| Weight | 5.15 kg |
| Service & Support | Limited warranty - return to factory - lifetime | Technical support - 1 year |
| Country of origin | SG |
| Power | Internal power supply |
| Package Contents | Pointer card, mounting kit |
| Security | MD5 | SSL |
| Management Protocol | CLI, SNMP, Telnet, SSH, SSH-2, DHCP, SCP, HTTPS, HTTP, ICMP, TFTP, Syslog, SNMP 2c, SNMP 3, RMON |
| SKU / EAN | C1300X-48NGU-4X | 0889728647465 |
SINGULAR RECOMMENDS
For who
For IT teams and network administrators who need a rack-mountable, managed, stackable 48-port switch with PoE support and 10G uplinks.
Real reason to buy it
It brings 48-port L3 switching, PoE++ on selected ports, 10G SFP28 uplinks and a 740W PoE budget in a stackable platform.
Know before
This is a rack-mountable managed switch with an internal power supply and 2 x fans. The listing includes a pointer card and mounting kit; no other accessories are confirmed.
Features - Cisco - C1300X-48NGU-4X
Standard
48-Port
Port Speed
- 1 Gbps
- 2.5 Gbps
- 5 Gbps
- 10 Gbps
More Details
Product Code
CQ58280
EAN Code
0889728647465
Manufacturer
Cisco
