Cisco Catalyst 9200L C9200L-24P-4G-E 24-Port PoE+ L3 Switch
The Cisco Catalyst 9200L is a 24-port Layer 3 stackable Gigabit Ethernet switch for rack-mount deployments. It offers PoE+ on the copper ports, four Gigabit SFP uplinks and Cisco Catalyst 9200 Series features in a compact managed platform.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Type | Switch - 24 ports - L3 - stackable |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 (PoE+) + 4 x Gigabit SFP (uplink) |
| Power Over Ethernet | PoE+ |
| PoE Budget | 740 W |
| Stacking Bandwidth | 80 Gbps |
| Switching Capacity | 56 Gbps |
| Forwarding Rate | 83.33 Mpps |
| Virtual Networks | 1 |
| IPv4 Routes | 11000 |
| IPv4 Routing Table Entries | 3000 |
| IPv6 Routing Table Entries | 1500 |
| Multicast Scale | 1000 |
| ACL Scale Entries | 1500 |
| FNF Entries | 16000 |
| VLANs Supported | 1024 |
| SVIs | 512 |
| QoS Hardware Queues per Port | 8 |
| MAC Address Table Size | 16000 entries |
| Jumbo Frame Support | 9198 bytes |
| Routing Protocols | OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, PIM-SSM, policy-based routing (PBR), RIPng, MSTP |
| Management Protocols | SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF |
| Features | QoS, Cisco StackWise Technology, Rapid PVST+, SRR, PXE support, RSPAN, NetFlow, Energy Efficient Ethernet, MIB, CoS, FNF, 802.1x authentication, DSCP support, MACsec support, 6MB packet buffer, CoPP, SPAN, EEM, PIM, FHS, PVLAN support, CIR |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at |
| RAM | 2 GB |
| Flash Memory | 4 GB |
| Interfaces | 24 x 1000Base-T RJ-45 PoE+ - 30 W | 4 x 1000Base-X SFP uplink | 1 x network stack device | 1 x management (LAN) RJ-45 | 1 x console RJ-45 |
| Power Device | Internal power supply - hot-plug |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Voltage Required | AC 100-240 V (50 - 60 Hz) |
| Width | 44.5 cm |
| Depth | 4.4 cm |
| Height | 28.8 cm |
| Weight | 4.35 kg |
| Service & Support | Limited warranty - advance parts replacement - lifetime - response time: next business day |
| Power | Internal power supply - hot-plug |
| Management Protocol | SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF |
| SKU / EAN | C9200L-24P-4G-E | 0889728170161 |
SINGULAR RECOMMENDS
For who
For IT teams that need a rack-mountable 24-port managed switch with PoE+, Layer 3 capability and Gigabit SFP uplinks.
Real reason to buy it
It combines 24 PoE+ access ports, four uplinks and Cisco StackWise support in a managed Catalyst platform with a 740 W PoE budget.
Know before
This model is rack-mountable and uses an internal hot-plug power supply. Optional power redundancy is supported, and the listed warranty is lifetime advance parts replacement with next business day response time.
