Cisco Catalyst 9300 C9300-24T-A 24-Port Gigabit Managed Layer 3 Switch Network Advantage StackWise-480 Modular Uplinks

Brand:
Cisco
Cisco Catalyst 9300 Network Advantage switch L3 C930024T-A
Cisco Catalyst 9300 C9300-24T-A 24-Port Gigabit Managed Layer 3 Switch Network Advantage StackWise-480 Modular Uplinks
€4572.3 inc. VAT
Buy
C9300-24T-A
€3,842.27 €4,269.19
€4,572.30 inc. VAT
Ships from EU stock: 10 item(s)
+ −
Add to wish list Ask a question
Product Code
677LB73
EAN Code
0889728051675
Manufacturer
Cisco
Quick Specs
Ports
24 × 1G RJ-45 (data)
Stacking
StackWise-480 (480 Gbps)
Management
Layer 3 · Network Advantage
Switching Capacity
208 Gbps
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

Cisco Catalyst 9300 C9300-24T-A 24-Port Managed Layer 3 Switch

24 × 1G Data PortsNetwork AdvantageStackWise-480UADP 2.0 ASIC

The Cisco Catalyst 9300 C9300-24T-A is a 24-port Gigabit managed Layer 3 enterprise access switch with the Network Advantage license, built on the programmable Cisco UADP 2.0 ASIC for line-rate, non-blocking performance. With 24 dedicated 10/100/1000 data ports, a modular uplink slot and StackWise-480 stacking, it is the foundational building block for Cisco SD-Access campus networks.

Identified by part number C9300-24T-A, this enterprise switch ships with a 350W AC power supply and supports redundant power, StackPower and up to eight stacked members. Typically in stock with fast delivery across Cyprus.

Good to know before you buy
The uplink network module is not included — add a C9300-NM module (1G, 10G, 25G or 40G) for uplinks. The switch ships with one 350W AC power supply; a second is optional for redundancy. The Network Advantage perpetual license is included, but Cisco requires a separate Cisco DNA / Catalyst term subscription (3, 5 or 7 years) at purchase. StackWise-480 and StackPower cables are sold separately. This is a data-only model with no PoE; it is configured via Cisco IOS XE and suited to networking professionals.

Best For

✓Enterprise campus and branch access-layer deployments
✓Cisco SD-Access and intent-based networking foundations
✓High-availability stacks of up to 8 switches (StackWise-480)
✓Layer 3 routing, segmentation and advanced security policy
✓Networks needing flexible 1G/10G/25G/40G modular uplinks
✓Application hosting and programmable automation at the access layer

Key Features


Programmable UADP 2.0 ASIC
An x86 multicore CPU with 8 GB DRAM and 16 GB flash drives the Cisco UADP 2.0 ASIC for line-rate, non-blocking IPv4/IPv6 forwarding and container app hosting.

StackWise-480 & StackPower
Stack up to eight switches over a 480 Gbps back-panel for a single managed unit, with StackPower pooling power supplies for resiliency.

Network Advantage Layer 3
Advanced Layer 3 routing (OSPF, BGP, MPLS), SD-Access, MACsec encryption and full automation — Network Advantage is inclusive of Network Essentials.

Modular Uplink Flexibility
A network-module slot accepts 1G, 10G, 25G or 40G uplink modules, so the uplink backbone can scale to match current and future needs.

Technical Specifications

Identification
Part NumberC9300-24T-A
EAN / GTIN0889728051675
MPNC9300-24T-A
BrandCisco
SeriesCatalyst 9300
Ports & Performance
Data Ports24 × 10/100/1000 RJ-45 (data only, no PoE)
Uplinks1 modular network-module slot (1G/10G/25G/40G) — module sold separately
Switch TypeManaged Layer 3 (Cisco IOS XE)
ASICCisco UADP 2.0
CPU / Memoryx86 multicore CPU, 8 GB DRAM, 16 GB flash
StorageUSB 3.0 SSD slot (up to 240 GB optional) + USB 2.0
Switching Capacity208 Gbps (688 Gbps stacked)
Forwarding Rate154.76 Mpps (511.90 Mpps stacked)
Stacking
Data StackingStackWise-480 — 480 Gbps back-panel, up to 8 members
Power StackingCisco StackPower (cables sold separately)
Software & Licensing
LicenseNetwork Advantage (perpetual, inclusive of Network Essentials)
SubscriptionRequires Cisco DNA / Catalyst term license (3/5/7 yr), sold separately
Key CapabilitiesLayer 3 routing, SD-Access, MACsec, PVRST+, MPLS, app hosting
Power & Physical
Power Supply350W AC default (PWR-C1-350WAC-P); dual redundant capable
Cooling3 field-replaceable fans
Form Factor1U, 19-inch rack mountable
Dimensions (H×W×D)4.45 × 44.5 × 44.5 cm
Weightapprox. 6.36 kg
ColourGrey (metal housing)
In the BoxSwitch, 350W AC power supply, 3 fans (uplink module & stack cables separate)

Frequently Asked Questions

Does the C9300-24T-A include uplink ports?
No. It has a modular network-module slot, but the uplink module (1G, 10G, 25G or 40G, e.g. C9300-NM-4G/8X/2Y/2Q) is sold separately and must be added for uplinks.
What is the difference between the -A and -E versions?
The -A suffix denotes the Network Advantage license, which includes advanced Layer 3 routing, SD-Access and automation. The -E (Network Essentials) version covers core switching features. Network Advantage is inclusive of Network Essentials.
Does the C9300-24T-A provide PoE?
No. The 24T is a data-only model with no Power over Ethernet. For PoE/PoE+ or UPOE, choose a C9300-24P, 24U or 24H variant instead.
Do I need a separate subscription license?
Yes. Although the Network Advantage perpetual license is included, Cisco requires a Cisco DNA / Catalyst term subscription (3, 5 or 7 years) to be purchased with the switch. It can be renewed or deactivated at term end.
Singular Expert Insight
The C9300-24T-A is enterprise access-layer hardware, not a plug-and-play office switch — its strengths are SD-Access, StackWise-480 high availability and the programmable UADP ASIC, all unlocked by the Network Advantage license. Two things to budget for: the uplink module and the mandatory Cisco DNA/Catalyst subscription, neither of which is in the box. If you only need basic Layer 2/3 switching without SD-Access, the Network Essentials (-E) variant is more economical. For simpler sites, an unmanaged or lightly managed switch from our network switches range may be a better fit, and Catalyst stacks pair well with enterprise access points.

Buyer’s Guide

Buy it if
You are building an enterprise campus with SD-Access, need Layer 3 routing and StackWise-480 high availability, and want Network Advantage features on 24 Gigabit data ports.
Skip it if
You need PoE for cameras or access points, want plug-and-play simplicity, or do not need SD-Access/advanced routing — the licensing and uplink costs would be wasted.
Also consider
The C9300-24T-E (Network Essentials) to lower cost, a C9300-24P/24U for PoE, or a C9300-48T for higher port density at the access layer.
