Club 3D CSV-1383 HDMI 2.0 Splitter 1x8 4K 60Hz HDR 3D with Metal Housing Black

Brand:
Club 3D
Club 3D CSV-1383 - Video/audio splitter - 8 x HDMI - desktop
Club 3D CSV-1383 HDMI 2.0 Splitter 1x8 4K 60Hz HDR 3D with Metal Housing Black
€161.99 inc. VAT
Buy
CSV-1383
€136.13
€161.99 inc. VAT
Ships from EU stock: 2 item(s)
+ −
Add to wish list Ask a question
Product Code
04:446207
EAN Code
8719214472771
Manufacturer
Club 3D
Quick Specs
Type
1x8 HDMI splitter
Connectors
1x HDMI in · 8x HDMI out
Key spec
4K 60Hz · 18 Gbps · HDR
Compatibility
HDCP 2.2 · 3D
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

Club 3D CSV-1383 1 to 8 HDMI Splitter, Full 3D and 4K 60Hz

4K 60Hz1 in · 8 outHDR · HDCP 2.2600 MHz

The Club 3D CSV-1383 is a 1x8 HDMI 2.0 splitter that duplicates one source to eight displays at up to 4K 60Hz, with HDR, 12-bit colour and full 3D support. It fits signage walls, classrooms, bars and retail spaces where eight screens show the same content.

The 600 MHz (18 Gbps) signal path carries 24/30/50/60 Hz 4K as well as interlaced formats, and HDCP 2.2 keeps protected content playing. A sturdy metal chassis and a 5V/3A power supply with over-voltage cut-off are included.

Compatibility note: The CSV-1383 does not convert, upscale or downscale — every output receives the source resolution, so all eight displays should support the format the source sends.

Key Features


Eight 4K 60Hz outputs
Full 600 MHz bandwidth drives UHD 4K at up to 60 Hz on eight HDMI outputs simultaneously, with 12-bit colour and HDR pass-through.

Full 3D and legacy formats
Supports 3D content plus progressive and interlaced formats including 480i, 576i and 1080i, so older sources work alongside 4K players.

Robust metal chassis
The 25.8 x 11.35 x 3.5 cm metal housing and 5V/3A supply (11.3 W max) with cut-off above 5.5 V are designed for continuous operation.

Technical Specifications

Identification
Part Number CSV-1383
EAN / GTIN 8719214472771
MPN CSV-1383
Brand Club 3D
Video & Signal
HDMI standard HDMI 2.0
Max resolution 4K @ 24/30/50/60 Hz; 480i/576i/1080i interlaced supported
Bandwidth 600 MHz — 6 Gbps per channel, 18 Gbps total
Colour depth 12-bit
HDR Supported
3D Supported
HDCP HDCP 2.2
Audio Compressed audio pass-through
Scaling None — no conversion, upscaling or downscaling
Ports
Input 1 x HDMI
Outputs 8 x HDMI (simultaneous, mirrored)
Physical & Power
Housing Metal, black
Dimensions 25.8 x 11.35 x 3.5 cm
Weight 770 g (1034 g with power supply)
Power supply 100–240 V AC to 5V / 3A DC adapter (included)
Power consumption 11.3 W max; cuts out above 5.5 V input
Package
In the box CSV-1383 splitter, power supply, QR code for the quick installation guide

Frequently Asked Questions

Can the Club 3D CSV-1383 downscale 4K for Full HD TVs?
No. Club 3D states that the CSV-1383 does not convert, upscale or downscale, so a 4K source should be set to a resolution every connected display supports. For mixed 4K and 1080p screens choose a splitter with a downscaler.
Is the CSV-1383 suitable for eight 4K signage screens?
Yes. With 18 Gbps bandwidth and HDCP 2.2 it sends 4K 60Hz HDR content from a signage player or PC to eight identical 4K displays.
What is the difference between the CSV-1383 and the CSV-1380?
Both are Club 3D HDMI 2.0 4K60 splitters. The CSV-1383 has eight outputs, HDR and a larger 5V/3A chassis, while the CSV-1380 has four outputs in a compact 156 g housing.
Singular Expert Insight
The Club 3D CSV-1383 is a solid eight-output 4K 60Hz splitter when all your displays are identical 4K panels, as in a uniform signage wall. If some screens are Full HD, the DIGITUS DS-55338 or Manhattan 208451 with downscaling are better suited. Compare all video splitters.
✓ Buy it if you drive eight identical 4K displays from one HDR source.
✕ Skip it if your screens mix 4K and Full HD resolutions.
→ Also consider Manhattan 208451 or DIGITUS DS-55338 for 1x8 with downscaling.
