Custom VKP80III / Side connection / receipt printer / thermal transfer / Roll (8.25 cm) / 203 dpi / up to 250 mm/sec / USB 2.0, LAN | 915DX010100J00
Please sign in so that we can notify you about a reply
Custom VKP80III / Side connection / receipt printer / thermal transfer / Roll (8.25 cm) / 203 dpi / up to 250 mm/sec / USB 2.0, LAN | 915DX010100J00
Special Features
- Flexible: roll holder separate from the printer body, with ergonomic system for paper loading from the right or left side, suitable for all types of kiosks
- Automatic ticket presenter
- Retracting function without ticket presentation
- Hot swap function: the printer can be removed from the kiosk without powering it off
- Print head with auto-diagnostic function: it is possible to get the number of non-working dots
- Label management: transparent alignment exploiting the mobile notch sensor and the paper sensor
Product Specification
| Printer Type | Receipt printer - thermal transfer - monochrome |
| Print Speed | Up to 250 mm/sec - max speed |
| Connectivity Technology | Wired |
| Interface | USB 2.0, LAN |
| Max Resolution (B&W) | 203 dpi |
| Language Simulation | CUSTOM/POS, True Font monospace |
| Styles & Effects | Bold, normal, italic, underline, rotated text, enlarged text |
| Barcodes | Code 93, Code 39, QR code, Aztec code, Code 32, UPC-A, UPC-E, Codabar, Code 128, PDF417, Data Matrix, ITF, EAN-8, EAN-13 |
| RAM Installed (Max) | 1 MB |
| Flash Memory | 5 MB |
| Media Type | Thermal paper |
| Max Media Size | Roll (8.25 cm) |
| Min Media Size (Custom) | 50 mm |
| Max Media Size (Custom) | 82.5 mm |
| Media Sizes | Roll (8.25 cm) |
| Media Weight | 60 g/m² - 110 g/m² |
| Roll Maximum Outer Diameter | 180 mm |
| Roll Core Diameter | 26.5 mm |
| Media Feeders | 1 x manual - 1 roll - Roll (8.25 cm) |
| Connections | 1 x USB 2.0 ¦ 1 x LAN - RJ-45 |
| Included Accessories | Paper roll holder, starter kit, NPE cable kit, NPE kit, paper mouth (black with LED), shutter kit |
| Cables Included | 1 x mini-USB cable - 1 m |
| MTBF | 450,000 hour(s) |
| Power Device | Power adapter - external |
| Software Included | Custom PowerTool, Custom PrinterSet |
| OS Required | Microsoft Windows XP, Microsoft Windows 7, Microsoft Windows Vista, Linux (64-bit), Windows 8, Linux (32-bit) |
| Min Operating Temperature | -20 °C |
| Max Operating Temperature | 70 °C |
| Width | 11.6 cm |
| Depth | 14.35 cm |
| Height | 7.64 cm |
| Weight | 800 g |
