D-Link DGS 1210-10 / Switch / smart / 8 x 10/100/1000 + 2 x Gigabit SFP / desktop, rack-mountable | DGS-1210-10/E
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Switch - 10 ports - smart |
| Enclosure Type | Desktop, rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 8 x 10/100/1000 + 2 x Gigabit SFP |
| Performance | Switching capacity: 20 Gbps ¦ Forwarding performance (64-byte packet size): 14.88 Mpps |
| Capacity | Static MAC entries: up to 256 ¦ IGMP groups: 256 ¦ QoS hardware queues per port: 8 ¦ ACL rules: 768 |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 10000 bytes |
| Routing Protocol | IGMPv2, IGMP, static IP routing, MLDv2, MLD |
| Remote Management Protocol | SNMP 1, RMON 1, Telnet, SNMP 3, SNMP 2c, TFTP, CLI |
| Encryption Algorithm | MD5, SSL, TLS, TLS 1.0, SSL 3.0, SSL 2.0, TTLS |
| Authentication Method | RADIUS, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
| Features | Flow control, full duplex capability, BOOTP support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack prevention, port mirroring, store and forward, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), MLD snooping, Safeguard Engine, D-Link Green Technology, fanless, LLDP support, TFTP client, LLDP-MED, Weighted Round Robin (WRR), loopback detection, 4.1Mbit packet buffer, auto voice VLAN, anti-ARP spoofing |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.3az |
| RAM | 128 MB DDR3 SDRAM |
| Flash Memory | 32 MB |
| Status Indicators | Power, link/activity/speed |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 8 x 1000Base-T RJ-45 ¦ 2 x 1000Base-X SFP |
| Power | Power |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 6.33 Watt |
| Power Consumption Stand by | 2.07 Watt |
| Miscellaneous | Miscellaneous |
| MTBF | 1,380,058 hours |
| Compliant Standards | FCC Class A certified, UL, BSMI, CB, CCC, VCCI Class A |
| Localisation | Europe |
| Software / System Requirements | Software / System Requirements |
| Software Included | D-Link Network Assistant |
| Dimensions & Weight | Dimensions & Weight |
| Width | 28 cm |
| Depth | 12.6 cm |
| Height | 4.4 cm |
| Weight | 980 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -5 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 0 - 95% |
| Min Storage Temperature | -20 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 0 - 95% |
Features - D-Link - DGS-1210-10/E
General
8-Port
More Details
Product Code
CE80036
EAN Code
0790069467707
Manufacturer
D-Link
