Datalogic CAB-364 — Coiled RS-232 DB-25 Cable for QuickScan and Touch Scanners
RS-232 serialDB-25 maleCoiled, 2 mQuickScan 2100 / TD1100
The Datalogic CAB-364 (part number 90A051350) is the official coiled RS-232 interface cable with a 25-pin male connector, used to connect a Datalogic QuickScan 2100 Series or Touch TD1100 handheld scanner to a POS terminal, PLC or legacy computer with a DB-25 serial port. Datalogic specifies it at 6.5 ft (about 2 m).
Power for the scanner is taken either from pin 9 of the host connector or from an external power supply, per Datalogic's description — so check what your host provides before ordering.
Before you order: Datalogic lists CAB-364 for the QuickScan 2100 Series and the Touch TD1100. It is not listed for Magellan, Gryphon 4200, QuickScan 2200 or QuickScan 2500 scanners. The host must have a 25-pin RS-232 port and supply power on pin 9 — otherwise you need an external power supply.
What's in the Box
- 1 × Datalogic CAB-364 coiled RS-232 cable, DB-25 male (90A051350)
- Power supply not included
What It Means in Practice
- Lets a modern QuickScan talk to older serial equipment — cash registers, industrial controllers, terminals — that has a 25-pin RS-232 port.
- The coiled cord keeps the scanner tethered without cable spread across the counter.
- If the host does not supply 5 V on pin 9, order the matching Datalogic power supply; the cable alone will not power the scanner.
- The scanner must be configured for the RS-232 interface (baud rate, parity) to match the host.
What Will Not Work
- It does not plug into a 9-pin DB-9 serial port or a USB port — DB-25 only.
- It is not listed for Magellan, Gryphon, QuickScan 2200 or 2500 scanners.
- It will not power the scanner if the host has no power on pin 9 and no external supply is used.
- It is not a USB-to-serial adapter.
Key Features
Official Datalogic cable
Part of the QuickScan 2100 and Touch TD1100 accessory lists.
DB-25 male host connector
For hosts with a 25-pin RS-232 port.
Flexible power
Power from pin 9 of the host connector or an external supply.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
Serial cables are where most scanner installs go wrong: connector size, gender and power on pin 9 all have to match. If your host has a 25-pin RS-232 port, CAB-364 is the official answer for QuickScan 2100 and TD1100 — browse our barcode scanners for the scanner itself.
✓ Buy it if you are connecting a QuickScan 2100 Series or Touch TD1100 to a host with a 25-pin RS-232 port.
✕ Skip it if your host uses USB or a 9-pin serial port, or your scanner is not in the listed families.
→ Also consider a Datalogic USB cable for PC/POS hosts with USB.
Not sure it fits your setup? Send us the model of your rack, switch or device and we will check compatibility before you order.
