Datalogic PowerScan PD9130 / Barcode scanner / handheld / linear imager / decoded / interface cable required | PD9130
|
Description The PowerScan PD9130 linear imager is a corded device offering incredible performance in an industrial product. This linear imager introduces Datalogic's innovative scanning technology, implementing a green scanning line which has the same definition of a laser beam with all the benefits of a linear imager. Datalogic PowerScan PD9130 / Barcode scanner / handheld / linear imager / decoded / interface cable required | PD9130Special Features
|
Product Specification
| Type | Barcode scanner - handheld |
| Colour | Black, yellow |
| Interface Type | Interface cable required |
| Minimum Bar Width | 2.5 mil |
| Scan Element Type | Linear imager |
| Scan Mode | Single-pass |
| Skew (Degrees) | 70 |
| Pitch (Degrees) | 75 |
| Print Contrast Signal (PCS) | 15% |
| Decode Capability | Code 93, Industrial 2 of 5, Code 39, IATA, ISBN, GS1 DataBar, Code 32, Code 39 Full ASCII, Codabar, Code 128, Code 11, Interleaved 2 of 5, Codablock F, Plessey, Standard 2 of 5, MSI, UPC/EAN supplementals, Datalogic 2 of 5, Code 39 CIP, Code 4, Code 5 |
| TTL Decoding | Decoded |
| Connectivity Technology | Wireless |
| OK Notification | Beeper, LED indicator |
| Features | ESD (electrostatic discharge) safe, Datalogic Three Green Lights (3GL) |
| Wireless Connectivity | RF |
| Compliant Standards | RoHS, IP65, IEC 62471 |
| Power Device | Power adapter |
| Software Included | Datalogic Aladdin, OPOS/JavaPOS Drivers |
| Width | 7.4 cm |
| Depth | 11 cm |
| Height | 21.2 cm |
| Service & Support | Limited warranty - 3 years |
| Min Operating Temperature | -20 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Drop Specification | 2 m to concrete |
Features - Datalogic - PD9130
More Details
Product Code
V383728
EAN Code
-
Manufacturer
Datalogic
