Datalogic QuickScan QD2590 1D/2D Barcode Scanner, 1 MP, scanner only, cable required, Black

Brand:
Datalogic
Datalogic QuickScan QD2590 Black 2D Barcode Scanner Scanner Only
Datalogic QuickScan QD2590 1D/2D Barcode Scanner, 1 MP, scanner only, cable required, Black
€116.81 inc. VAT
Buy
QD2590-BK
€98.16
€116.81 inc. VAT
Ships from EU stock: 16 item(s)
+ −
Add to wish list Ask a question
Product Code
CB00166
EAN Code
5704174633099
Manufacturer
Datalogic

Quick Specs

Reads
1D / 2D / screen codes
Host interfaces
USB / RS-232 (appropriate cable)
Package
Scanner only; no cable or stand.
Engine
1 MP · 1280 × 800 · IP52
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

QuickScan QD2590 · scanner only, cable required

1D + 2D1 MP imagerUSB / RS-232Black

QD2590-BK is the black scanner-only configuration for installations where the interface cable is chosen separately. It provides the same documented megapixel QD2590 reading engine as the USB kits, while letting you plan the connection around an existing workstation.

Before you order:
No interface cable or stand is included. Select the appropriate Datalogic USB or RS-232 cable for your host; a cable pictured in an application view does not mean it is supplied. BKK1 includes a USB cable, while BKK1S also includes the stand.

What's in the Box

  • QD2590 black scanner

What It Means in Practice

  • Useful as a replacement reader only after checking the exact existing cable and host requirements.
  • Avoid comparing scanner-only and USB-kit prices without accounting for the cable and any support stand.
  • The megapixel engine handles 1D/2D and screens; wireless movement still requires another scanner type.

What Will Not Work

  • QD2590 is corded; Bluetooth and radio operation belong to different QuickScan models.
  • A compatible interface cable must be ordered before use.

Key Features


Megapixel decoding
The 1280 × 800 imager supports 1D/2D, screen codes, OCR-A/OCR-B/MICR and Digimarc as documented for the QD family.

Precise aiming and confirmation
Blue aiming triangles and Green Spot help select the right code and confirm successful reading.

Flexible wired host selection
USB and RS-232 support let you choose the host interface with the corresponding cable and configuration.

Technical Specifications

Identification
Manufacturer SKU QD2590-BK
EAN / GTIN 5704174633099
Reading
Engine 1 MP imager / 1280 × 800
Barcode families 1D / GS1 DataBar, QR / Micro QR / Data Matrix / Aztec / Han Xin / MaxiCode / DotCode, PDF417 / MicroPDF417, postal / composite
Minimum code sizes 1D 3 mil / PDF417 3 mil / Data Matrix 5 mil / QR 6.7 mil
Typical reading ranges Code39 5 mil: 0.5–25 cm; 10 mil: 0.5–38 cm; Data Matrix10 mil: 0.5–21.5 cm; EAN/UPC13 mil: 0.5–51 cm; PDF4176.7 mil: 0.5–21 cm; QR20 mil: 0–37 cm
Range conditions Depend on symbol length, scan angle, print resolution, contrast and ambient light
Aimer / illumination Blue LED triangles / red LED
Motion tolerance 30 IPS
Minimum contrast 15%
Angles Pitch ±65° / roll 360° / skew ±65°
Read confirmation Green Spot / LED / adjustable beeper
Interfaces & power
Supported host interfaces USB / USB-C / RS-232; suitable cable required
Power 5 V DC
Current Operating below 400 mA; idle below 90 mA, at 5 V
Physical & environment
Dimensions / weight 148 × 68 × 126 mm / 145 g
Protection / drops IP52 / repeated 1.5 m drops onto concrete
Ambient light 0–110000 lux
Temperature Operating 0–50 °C; storage/transport -40–70 °C
Humidity / ESD 0–95% non-condensing /16 kV air discharge
Trigger endurance 10 million activations
Utilities Datalogic Aladdin / OPOS / JavaPOS; application setup required
Manufacturer term 5-year factory warranty, manufacturer terms apply
Advanced decoding Digimarc / OCR-A / OCR-B / MICR
Colour Black

Frequently Asked Questions

Can I use it immediately without a cable?
No. This is a corded reader and the appropriate interface cable is sold separately.
Which kit avoids ordering a USB cable separately?
QD2590-BKK1 includes USB cable90A052258. BKK1S includes that cable and an Auto Flex stand.
Singular Expert Insight
Choose BK when the cable is a deliberate part of the installation plan, not as a cheaper-looking substitute for a complete USB kit. Confirm an existing lead’s compatibility before reuse; otherwise BKK1 makes the supplied USB connection explicit and BKK1S adds the stand. Compare barcode scanners

Buyer’s Guide

✓

Buy it if

 You need the black reader with a separately selected compatible cable.
✕

Skip it if

 You expect a USB cable or stand in this package.
→

Also consider

 BKK1 for the USB cable kit; BKK1S for cable and Auto Flex stand.
Tell us your POS model, application and barcode examples so we can check the connection requirements.
