DIGITUS DN-96800S-2 — Fiber Optic Unibox for Wall Mounting, Small
Up to 24 fibersWall mount · indoorLockableGrey RAL 7035
The DIGITUS DN-96800S-2 is a compact, lockable wall-mount fiber optic splice box (Unibox) for indoor use, taking up to 24 fibers. It is used where a fiber cable enters a building, floor or technical room and needs to be spliced and patched without a 19" rack.
The housing is cold-rolled steel, powder-coated light grey RAL 7035, measuring 265 × 150 × 55 mm. Cables enter and exit at the top and bottom through foam-rubber strips, and built-in fixing points hold the cables with ties. The box ships unequipped: you choose the adapter plate that matches your connectors.
Before you order: The Unibox comes WITHOUT adapter plate, couplers, pigtails or splice cassettes. To fit couplers you need an adapter plate — DIGITUS DN-96801S-2 (12 ports SC simplex / LC duplex / E2000 simplex) or DN-96803S-2 (6 × SC duplex / LC quad).
What's in the Box
- 1 × DIGITUS fiber optic Unibox for wall mounting, small (DN-96800S-2)
- 2 × keys
- Mounting material: screws, dowels, washers, cable ties
- No adapter plate, couplers, pigtails or splice cassettes
What It Means in Practice
- Up to 24 fibers when fitted with an LC-quad or LC-duplex adapter plate and matching pigtails.
- Lockable door keeps patch connections away from unauthorised hands in shared corridors or plant rooms.
- IP20: for dry indoor locations only.
- Foam-rubber entry strips seal around cables top and bottom without separate glands.
What Will Not Work
- Couplers cannot be fitted without the separate adapter plate.
- It is not suitable outdoors or in damp rooms (IP20).
- It does not mount in a 19" rack.
- No splice cassettes are included — add cassettes for your splice count.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
The small Unibox is a tidy, lockable fiber termination point for a wall — ideal for building entry points and floor distributors without a rack. Order the adapter plate with it, or the box arrives with nowhere to put the couplers. For the active side, browse our switches.
✓ Buy it if you need an indoor, lockable wall splice box for up to 24 fibers.
✕ Skip it if the location is damp or outdoors, or you need more capacity.
→ Also consider DIGITUS DN-968912 for a small IP65 outdoor termination.
Tell us your fiber count and connector type and we will put together the Unibox, adapter plate, couplers and pigtails before you order.
Features - Digitus - DN-96800S-2
Colour
grey
More Details
Product Code
04:347346
EAN Code
4016032466093
Manufacturer
Digitus
