DIGITUS - DisplayPort adapter - Mini DisplayPort (M) to DisplayPort (M) - DisplayPort 1.4 - 2 m - 4K120Hz support - black | DB-340201-020-S

Product Features

· Resolution: 7680 x 4320p / 60 Hz (UHD-2)
· Supports 8K 3D
· Data transfer rate of up to 32.4 Gbps (max. bandwidth)
· Supports up to 120Hz at 4K & Full HD (1080p)
· Subsampling: YUV 4:4:4
· HDCP version: 2.2
· DisplayPort version: 1.4
· Supported color depth: 16 Bit Deep Color
· Supports HDR
· Supports Consumer Electronic Control (CEC)
· Supports Lip Sync (audio/video synchronization)
· Supports stereoscopic 3D video
· Supports Display Stream Compression 1.2 (DSC)
· Supports EDID 2.0 (device recognition)
· Supports DVI Version 1.0 (in conjunction with adapters)
· Supports forward error correction (FEC)
· Multi Stream audio/video support
· Supports 21:9 Cinemascope
· 32 channel audio support
· Dolby TrueHD capable
· Supports 8-channel LPCM, 192 kHz, 24-bit audio capability
· Supports DTS-HD Master Audio bitstream
· Supports Super Audio CD (DSD)
· Supports DVD audio
· Supports Blu-ray Disc and HD DVD audio and video
· Cable diameter: 6.8 mm
· OM version: OM3
· Operating temperature: -20 ~ 60°C
· Operating humidity: 0 - 95% RH
· Connection 1: DP, Plug
· Connection 2: DP, Plug
· Locking mechanism: Snap-in fastening
· AWG: 30
· DisplayPort standard: DisplayPort 1.4
· Cable color: black
· Hood: Aluminum housing
· HDTV standard: Ultra HD 8K
· Contact surface: gold-plated Length: 2 m AOC - Active Optic Cable: no Shielding: double shielding

Special Fetures

· DisplayPort plug to DisplayPort plug
· Connects PC/Computer, notebook or graphics card for gaming with DP-capable devices such as TVs, screens, monitors, projectors, displays
· Supports the video formats 4K/2K@120Hz, 5K@60Hz or 8K@60Hz and resolutions of 3840 x 2160p, 5120 x 2880p and 7680 x 4320p - Also enables a color depth of 24 bits
· Compatible with DP standards 1.4, 1.3 and 1.2
· The gold-plated precision plugs provide optimal signal quality and corrosion protection
· With aluminum housing and nylon mesh, the cable offers optimal quality and protection.

Product Specification

Type	DisplayPort adapter
Technology	Double shielded
Plated Connector	Gold
Features	4K120Hz support, Ultra HD (8K) support, 32 audio channels, 16-bit deep colour, Lip-Snyc supports, DVD Audio, DTS-HD support, Dolby TrueHD support, 3D support
Length	2 m
Colour	Black
Width	16 cm
Depth	16 cm
Height	2 cm
Weight	15 g
Connectivity
Connector	Mini DisplayPort - male
Connector (Second End)	20 pin DisplayPort - male
Miscellaneous
Compliant Standards	DisplayPort 1.4, CEC, OM3, HDCP 2.2, EDID 2.0
