Digitus DN-93601 Cat.6 Class E Keystone Module, Unshielded, LSA
Cat.6 Class E250 MHzUTPLSA termination
The Digitus DN-93601 is an unshielded Cat.6 keystone module: an RJ45 socket with LSA punch-down terminals that snaps into keystone patch panels, surface boxes and faceplates. It is rated Class E up to 250 MHz for Gigabit Ethernet and suits installers and IT teams building or extending a U/UTP Cat.6 network.
Digitus specifies it to ISO/IEC 11801 3rd Ed., EN 50173-1 and EIA/TIA 568-C, with colour-coded LSA strips for both T568A and T568B, a quick-latch cable retention, and gold-plated contacts. It accepts solid and stranded wire from 22 to 26 AWG.
Before you order: This is an unshielded module. In a shielded (F/UTP, S/FTP) installation use a shielded keystone so the shield is carried through.
What's in the Box
- 1 x Digitus DN-93601 Cat.6 keystone module, unshielded, white
What It Means in Practice
- Terminate installation cable on the LSA strips and click the module into any keystone panel or outlet.
- Class E means Gigabit Ethernet over a Cat.6 permanent link and channel.
- Rated for more than 750 plug cycles and more than 200 re-terminations, so it survives moves and changes.
What Will Not Work
- It will not carry a cable shield: no shield contact.
- It is not tool-free: an LSA punch-down tool is required (not included).
- It is not rated Cat.6A or 10GBase-T over 100 m; for 10 Gigabit choose a Cat.6A module.
Key Features
Class E performance
ISO/IEC 11801 3rd Ed., EN 50173-1, EIA/TIA 568-C.
T568A / T568B
Colour-coded LSA strips for both wiring schemes.
Durable contacts
Gold-plated contact area, >750 mating cycles.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
Keystone modules let you build a patch panel or wall outlet port by port and replace a single port without touching the rest. Once installed, patch from the panel to the switch with short network patch cables.
✓ Buy it if you are building or repairing an unshielded Cat.6 installation with keystone panels or outlets.
✕ Skip it if your cabling is shielded or you need Cat.6A / 10 Gigabit.
→ Also consider Equip 125122 2-port keystone surface box; EFB EC020100003 Cat.6A shielded keystone.
Not sure it fits your setup? Send us the model of your rack, switch or device and we will check compatibility before you order.
Features - Digitus - DN-93601
Colour
white
More Details
Product Code
04:99061
EAN Code
4016032245100
Manufacturer
Digitus
