Digitus DN-95102-1 — 802.3af PoE for one Gigabit device
IEEE 802.3af · 15.4 WGigabit pass-throughInternal PSUPlug and play
The Digitus DN-95102-1 is a single-port Gigabit PoE injector that adds IEEE 802.3af power — 15.4 W at 48 V DC — to an existing Ethernet link. It suits offices and small installations that want to run one IP phone, fixed IP camera or entry-level access point from a switch without PoE.
The power supply is built in: you plug the injector into the mains with a standard power cord, connect the switch to the LAN port and the device to the PoE port. Data passes at 10/100/1000 Mbps, and the injector only applies power after it detects and classifies a compliant PoE device.
Before you order: This model is 802.3af only (15.4 W). It is not a PoE+ injector, even though some documents use that word: Wi-Fi 6 access points, PTZ cameras and devices that need more than about 13 W at the device will not run reliably.
What's in the Box
- DN-95102-1 PoE injector
- Power cord
- Quick start guide
What It Means in Practice
- One cable to the device carries data and power — no power adapter or socket is needed at the ceiling or wall where the device sits.
- Use it to add a single PoE device to a non-PoE switch or router.
- Power travels on the spare pairs (4/5 and 7/8), the most common arrangement for 802.3af midspans.
- Self-consumption is low (max. 1.6 W), so it can stay powered permanently.
What Will Not Work
- It does not power 802.3at (PoE+) or 802.3bt devices at full load.
- It does not provide 12 V DC for non-PoE devices — a splitter is needed for that.
- It is not a switch and does not add ports.
- It is for indoor use only.
Key Features
802.3af compliant
48 V DC, 15.4 W, 320 mA with detection and classification of the powered device.
Gigabit pass-through
10/100/1000 Mbps data on the same cable.
Built-in protection
Current limiting, short-circuit protection and 1.5 kA / 2 kV surge rating.
Clear status
AC Power and Active Load LEDs.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
For one IP phone or a simple fixed camera, an 802.3af injector is the cheapest way to avoid a local power adapter. Check the power class of the device first — if it asks for PoE+ or 802.3at, choose a 30 W injector. For devices that pair well with it, see our access points.
✓ Buy it if you need to power one 802.3af device up to 15.4 W from a non-PoE switch.
✕ Skip it if the device needs PoE+ (802.3at) or more — pick a 30 W injector.
→ Also consider a Gigabit 802.3at (30 W) PoE+ injector for modern access points and PTZ cameras.
Not sure it fits your setup? Send us the model of your rack, switch or device and we will check compatibility before you order.
Features - Digitus - DN-95102-1
More Details
Product Code
04:283584
EAN Code
4016032441120
Manufacturer
Digitus
