DIGITUS DN-9005-N Cat 6 Shielded Flush-Mount Wall Outlet, 2 × RJ45, LSA, White RAL9003

Brand:
Digitus
DIGITUS DN-9005-N White Shielded Cat 6 Dual RJ45 Flush-Mount Outlet
DIGITUS DN-9005-N Cat 6 Shielded Flush-Mount Wall Outlet, 2 × RJ45, LSA, White RAL9003
€11.48 inc. VAT
Buy
DN-9005-N
€9.65
€11.48 inc. VAT
Ships from EU stock: 15 item(s)
+ −
Add to wish list Ask a question
Product Code
04:59215
EAN Code
4016032175711
Manufacturer
Digitus

Quick Specs

Network
Cat 6; 250MHz; 1GBase-T
Ports
2 × shielded RJ45, 8P8C
Termination
Krone LSA+, T568A/B
Frame / centre
80 × 80mm / 50 × 50mm
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

Two shielded network ports at the wall

Cat 62 × RJ45Flush mountLSA T568A/B

DIGITUS DN-9005-N provides two shielded Cat 6 RJ45 ports in a white flush-mount outlet. Horizontal cable entry, LSA termination and integrated cable strain relief support a structured installation, while the angled sockets and dust covers keep the user-facing connections practical. The published application is up to 250MHz and 1GBase-T.

Compatibility — check before buying:
This is the single flush-mount DN-9005-N, not the surface-mount DN-9006-N or a five-piece set. The manufacturer explicitly excludes R&M freenet patch cords. Check the 80 × 80mm frame and 50 × 50mm centre against the intended installation.

Key Features


Two shielded RJ45 ports
The die-cast housing shields both the RJ45 sockets and the LSA termination area.

Structured cable termination
Krone LSA+ connections accept 22–26 AWG solid and stranded conductors, with T568A/B colour markings.

Angled, covered connections
The 40° angled sockets ease patch-cord routing and the central plate includes integrated dust covers.

Standard plate dimensions
An 80 × 80mm outer frame surrounds a 50 × 50mm central plate; check fit with the intended switch range.

Technical Specifications

Model / EAN DN-9005-N / 4016032175711
Network and installation
Category / application Cat 6; up to 250MHz; 1GBase-T
Ports 2 × RJ45 female, 8P8C
Mounting variant Flush-mount outlet
Cable entry / termination Horizontal entry; Krone LSA+, T568A/B colour coding
Conductor range 22–26 AWG solid and stranded
Shield / strain relief Fully shielded RJ45 and LSA; integrated installation-cable strain relief
Outlet angle 40° angled patch-cord sockets
Frame / central plate 80 × 80mm / 50 × 50mm
Dust protection Integrated dust covers in central plate
Colour White RAL9003
Compatibility exception Not compatible with R&M freenet patch cords
Materials
Housing Zinc die-cast metal
RJ45 body / contacts ABS UL94V-0 / tinned phosphor bronze, 0.5µm gold plating
RJ45 shield Tinned bronze
LSA clamp / board Zinc-plated phosphor bronze, UL94V-2 / FR4, UL94V-0
Electrical and mechanical
Insertion / retention 30N maximum / 7.7kg between jack and plug
Operating temperature −20°C to +70°C
Mating / clamp cycles More than 750 / more than 200
Insulation resistance Greater than 500MΩ
Contact resistance Less than 20mΩ
Dielectric strength 1000V DC contact/contact; 1500V DC contact/ground
Referenced standards ISO/IEC 11801 3rd Ed.; EN 50173-1; EIA/TIA 568-C; IEC 60603-7-5
Net weight 0.16kg
Package contents Outlet; mounting instruction

What's in the Box

Wall outlet
Mounting instruction

Frequently Asked Questions

Is a surface-mount box included?
The listed contents are the outlet and mounting instruction. DN-9005-N is the flush-mount model; do not assume that a separate surface-mount box is included.
Does it work with R&M freenet patch cords?
No. The manufacturer specifically states that this outlet is not compatible with R&M freenet patch cords.
Which conductors and wiring schemes are supported?
The LSA terminals accept 22–26 AWG solid and stranded conductors. Follow the T568A or T568B colour markings consistently throughout the link.
Singular Expert Insight
Check wall-box depth and faceplate fit before terminating the cable. Use one consistent wiring scheme throughout the link, maintain the cable manufacturer bend and termination rules, and protect the outlet from moisture. Ask about network outlet installation

Buyer’s Guide

Buy it if

You need two shielded Cat 6 ports in a compatible flush-mount installation.

Skip it if

You require the surface-mount variant, a five-piece pack or R&M freenet patch-cord compatibility.

Also consider

Check cable conductor gauge, wall-box space and faceplate dimensions before ordering.
