DrayTek Vigor2136 Wired 2.5G VPN Router, DE/AT/CH
Brand:
Draytek
v2136-DE-AT-CH
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Multi-gig wired routing with business VPN controls
2.5GbE WANConfigurable 2.5GbE P116 VPN tunnelsWired base model
The DrayTek Vigor2136 is a wired broadband VPN router for a configured home-office or small-business network. This v2136-DE-AT-CH base version combines a 2.5GbE WAN interface, a 2.5GbE P1 LAN port and three Gigabit LAN ports, plus two USB 2.0 connections. P1 can be used as a second WAN with compatible firmware. Firewall, VLAN, routing-policy and QoS controls let an administrator organize the network.
Best For: Wired offices and demanding home networks that need multi-gig Ethernet routing and compatible remote-access or site-to-site VPN, using separate Wi-Fi access points when required.
Before you order: This exact model has no built-in Wi-Fi, DSL modem, cellular modem or SFP slot. Connect a suitable Ethernet modem/ONT or Internet handoff. P1 LAN/WAN configuration and advanced features require compatible regional firmware; verify support before deployment. The DE/AT/CH retail package includes a regional power adapter, so confirm its plug suits the installation. VPN and security services may require compatible clients, setup and separate subscriptions.
What's in the Box
- Vigor2136 wired base router, regional SKU v2136-DE-AT-CH.
- Regional power adapter, RJ45 Ethernet cable and Quick Start Guide.
- German regional package lists two wall screws, two anchors and a drilling template. Antennas belong to ax models; modem/ONT, Wi-Fi access point and USB peripherals are separate.
What It Means in Practice
- Connect the fixed 2.5GbE WAN to an appropriate Ethernet Internet source and configure the ISP connection parameters.
- Use P1 at up to 2.5Gbps for LAN, or configure its second-WAN role with supported firmware; the three other LAN ports are Gigabit.
- Design VLANs, DHCP subnets, routing policies and QoS around the devices and services on the network.
- Choose supported VPN clients, protocols and authentication settings. Throughput depends on encryption, configuration and traffic.
- Use compatible USB modems, storage or printers only after checking the device support list. USB ports do not imply a built-in cellular radio.
What Will Not Work
- No integrated wireless coverage; the ax model is a different product.
- No direct DSL telephone-line or fibre-SFP termination, and no SIM slot on this base router.
- Five RJ45 sockets do not mean five 2.5GbE ports: there are two 2.5GbE and three Gigabit interfaces.
- Published NAT/VPN figures are manufacturer test maxima, rather than a guaranteed Internet or encrypted-data rate.
Key Features
A multi-gig Ethernet path
A fixed 2.5GbE WAN and a 2.5GbE P1 port support suitable Internet and LAN equipment.
Configurable VPN connectivity
Up to 16 VPN tunnels with supported IPsec, OpenVPN and WireGuard workflows; firmware and client compatibility apply.
Traffic and network organization
VLANs, multiple LAN subnets, routing policy and application-based QoS provide practical configuration controls.
Peripheral flexibility
Two USB 2.0 ports support listed compatible devices, while separate access points provide Wi-Fi when needed.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
Match the router to the Internet handoff and the network topology first. The wired Vigor2136 can sit behind a suitable modem/ONT and serve a separate access-point network. Decide whether P1 is more useful for a multi-gig LAN device or an additional WAN, and check the supported regional firmware before relying on that role.
Buyer’s Guide
✓ Buy it if You need a configurable wired VPN router with a 2.5GbE Internet path and separate wireless infrastructure.
✕ Skip it if You need built-in Wi-Fi, direct DSL/fibre-SFP termination, an integrated cellular modem or 2.5GbE on every LAN port.
→ Also consider ISP handoff, firmware, P1 role, VPN clients, subscription needs, local power plug and access points.
Features - Draytek - v2136-DE-AT-CH
Colour
white
Interface
- USB2.0,
- Ethernet
Standard
5-Port
Port Speed
- 10/100 Mbps,
- 1 Gbps,
- 2.5 Gbps
More Details
Product Code
04:492423
EAN Code
4710484748508
Manufacturer
Draytek
