Edimax EW-7811UAC — AC600 High-Gain USB Wi-Fi Adapter with Cradle
AC600 dual-bandHigh-gain antennaUSB cradle 1.2 mWPA3
The Edimax EW-7811UAC is an AC600 dual-band USB Wi-Fi adapter with an external high-gain antenna (4 dBi on 2.4 GHz, 6 dBi on 5 GHz) and a USB cradle on a 1.2 m cable, giving a desktop up to 433 Mbps on 5 GHz or 150 Mbps on 2.4 GHz from a spot where the signal is best.
The cradle is what sets it apart: instead of sitting behind the PC case, the adapter can stand on the desk or a shelf, closer to the router and away from metal — often the difference between a weak and a stable connection. It also supports WPA3 and runs on Windows, macOS and Linux.
Before you order: Edimax lists Windows 7/8/8.1/10/11, macOS 10.9–10.15 and Linux kernel 2.6.18–5.11. macOS 11 or later is not listed, so do not count on it for recent Macs.
What's in the Box
- EW-7811UAC USB adapter
- USB cradle with 1.2 m cable
- Edimax does not publish the rest of the package list
What It Means in Practice
- Put the cradle on the desk or high on a shelf with line of sight to the router for the best signal.
- 433 Mbps on 5 GHz suits streaming, video calls and office work.
- WPS button for one-press connection to compatible routers.
- Works directly in a laptop USB port too, without the cradle.
What Will Not Work
- Wi-Fi 6 speeds — this is an 802.11ac (Wi-Fi 5) adapter.
- macOS 11 Big Sur and later — not in Edimax's list.
- Linux kernels newer than 5.11 without your own driver build.
- USB-C-only laptops without a USB-A adapter.
Key Features
AC600 dual-band
433 Mbps 5 GHz + 150 Mbps 2.4 GHz.
High-gain antenna
4 dBi (2.4 GHz) / 6 dBi (5 GHz) external antenna for longer range.
USB cradle 1.2 m
Place the adapter where the signal is strongest.
WPA3 security
WPA3-SAE plus WPA2/WPA, 802.1x and WPS.
Technical Specifications
| Identification |
| Part Number |
EW-7811UAC |
| EAN / GTIN |
4710700929865 |
| Brand |
Edimax |
| Wireless |
| Standards |
IEEE 802.11ac/a (5 GHz), 802.11n/g/b (2.4 GHz) |
| Speed |
5 GHz 433 Mbps · 2.4 GHz 150 Mbps |
| Antenna |
External high-gain, 4 dBi (2.4 GHz) / 6 dBi (5 GHz) |
| Security |
WPA3-SAE, WPA2, WPA, WEP, 802.1x, WPS |
| Hardware |
| Interface |
USB 2.0 Type-A |
| Cradle |
USB cradle with 1.2 m cable |
| Button / LED |
1 WPS button, 1 LED |
| Weight |
18 g |
| System |
| OS |
Windows 7/8/8.1/10/11; macOS 10.9–10.15; Linux kernel 2.6.18–5.11 |
| Operating temperature |
0 to 40 °C |
| Certifications |
CE, FCC, IC |
| Warranty |
| Warranty |
1-Year Warranty (Singular) |
| Manufacturer Term |
Not published by the manufacturer for this model — claims handled through Singular |
Frequently Asked Questions
Why use the cradle?
Moving the adapter away from the PC case and up on the desk usually gives a clearly stronger and more stable signal.
Does it work on Windows 11?
Yes — Edimax lists Windows 11.
Will it work on my M1/M2 Mac?
Edimax lists macOS up to 10.15 only, so recent Macs are not supported.
Singular Expert Insight · Buyer's Guide
For a desktop far from the router, an adapter on a cradle often beats an internal card in the back of the case. The EW-7811UAC is a solid Wi-Fi 5 choice with WPA3; check your OS against Edimax's list first. More options in our
network adapters.
✓ Buy it if you need reliable dual-band Wi-Fi on a desktop and want to place the antenna on the desk.
✕ Skip it if you use a recent Mac or need Wi-Fi 6.
→ Also consider TP-Link Archer T2U Plus for a simpler high-gain adapter without cradle.
Not sure it works on your system? Send us the OS and PC model and we will check before you order.
