Edimax Pro MG-1000AS1 V2 Gigabit SFP Transceiver 1000BASE-LX 1310 nm LC Single-Mode up to 10 km
Brand:
Edimax
Edimax Pro MG-1000AS1 V2 Gigabit SFP Transceiver 1000BASE-LX 1310 nm LC Single-Mode up to 10 km
€30.11 inc. VAT
MG-1000AS1 V2
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Edimax Pro MG-1000AS1 V2 — Gigabit LX SFP, 10 km
1 Gbps1000BASE-LX1310 nm · LCUp to 10 km
The Edimax Pro MG-1000AS1 V2 is a Gigabit SFP module for single-mode fibre: 1000BASE-LX at 1310 nm over an LC/UPC duplex connection, up to 10 km on 9/125 µm fibre, with an 11.5 dB power budget. It is the standard LX module for Edimax Pro switches and for other switches and media converters with MSA-compliant SFP ports. In practice, single-mode optics are the choice when a link leaves the building or runs more than a few hundred metres: the 9/125 µm fibre used by carriers and campus backbones carries the signal for kilometres with little loss. Before you order, confirm the fibre is single-mode at both ends and note the length and the number of patch panels on the way.
Compatibility — check before buying:
It needs two single-mode fibres and a 1310 nm LX module at the far end; it will not run on multimode fibre (Edimax’s MG-1000AMB V2 is the 2 km multimode part) and will not pair with a single-strand BiDi module. It is rated 0 to 70 °C; for cabinets choose the industrial MG-1000AS1I. As a plain duplex LX optic it links to any standard 1000BASE-LX module, including the older V1. Keep the dust cap on until you connect the fibre, and clean both connector ends before every mating — dirt is the most common cause of a link that will not come up. Not sure? Send us your switch model and the cable run and we check it before you order.
Best For
✓ Gigabit links between buildings
✓ Edimax Pro switch uplinks
✓ Runs of up to 10 km on single-mode
✓ Switches that accept MSA optics
✓ Media converters with SFP slots
✓ Replacing a failed MG-1000AS1
Key Features
10 km with margin
An 11.5 dB power budget covers a 10 km single-mode run plus patch panels.
Single-mode fibre, long reach
Built for single-mode (9/125 µm) fibre, the type used between buildings, floors and sites. It will not run over the orange or aqua multimode fibre found in many racks — the fibre type has to match at both ends.
Hot-swappable
Modules plug into a live port without shutting the switch down, so a link can be added or replaced during working hours. Seat it until it clicks and use the latch to remove it.
Plan both ends together
A link only comes up when both ends use the same standard, speed and media. Order the far-end module, the patch cords and any spares in one go and the link works on day one.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
We fit the MG-1000AS1 V2 for Gigabit single-mode links on Edimax Pro and other open switches. Order the far-end LX module with it and use single-mode UPC cords. For outdoor cabinets, the industrial MG-1000AS1I is the right choice. Every order is backed by Singular’s local support in Cyprus — if a link will not come up, send us the port status and we help you find out whether it is the module, the cable or the configuration. Browse all transceivers or the switches they plug into.
Buyer’s Guide
Buy it if
You need a 1G link over duplex single-mode fibre up to 10 km in an indoor rack.
Skip it if
Your fibre is multimode, only one strand is free, or the module sits in an unheated cabinet.
Also consider
Edimax Pro MG-1000AS1I for industrial temperatures.
Features - Edimax - MG-1000AS1 V2
More Details
Product Code
04:230887
EAN Code
4717964701732
Manufacturer
Edimax
