EFB-Elektronik 691653TS.80 — 150 kg 1U Shelf for Deep 19-inch Cabinets
1U · 19-inch150 kg loadDepth 500–900 mmBlack RAL 9005
The EFB-Elektronik 691653TS.80 is a 1U heavy-duty 19-inch shelf with a 150 kg load rating and a depth adjustable from 500 to 900 mm, for 800–1000 mm deep network and server cabinets that need to carry UPS units, tower servers or heavy appliances.
Unlike a front-only cantilever shelf, it must be fixed to both the front and rear 19-inch profiles, which is what allows the 150 kg rating. The mounting depth is set with self-tapping screws, and the shelf takes only 1U of rack height. Finish: Black RAL 9005.
Before you order: EFB specifies this shelf for cabinets 800–1000 mm deep, fixed at front and rear. For 600 mm deep cabinets EFB offers a separate version with a 350–600 mm range — do not order this one for a 600 mm cabinet. Do not confuse it with the grey 691653GR.80.
What's in the Box
- 1 × heavy-duty shelf
What It Means in Practice
- 150 kg is enough for a rack UPS without rails, a tower server laid flat or a stack of appliances.
- Adjust the depth once to match your profile spacing, then fix with self-tapping screws.
- Only 1U tall, so it wastes little rack space under heavy equipment.
- Cage nuts and screws for the rack profiles are not listed in the box — use your cabinet's own M6 hardware.
What Will Not Work
- 2-post racks or wall brackets — the shelf needs front and rear profiles.
- 600 mm deep cabinets — there is a separate EFB version for them.
- Sliding access — it is a fixed shelf.
- 10-inch or 23-inch racks.
Key Features
150 kg rating
Heavy-duty 4-point support.
Depth adjustable
500–900 mm for 800–1000 mm cabinets.
1U profile
Minimal rack height used.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
Heavy loads belong on 4-point shelves, not cantilever ones, and this EFB shelf is the right base for a rack UPS or a server without rails. Check your cabinet depth, then browse our rack accessories range for cage nuts and blanking panels.
✓ Buy it if you need to carry up to 150 kg in an 800–1000 mm deep 19-inch cabinet.
✕ Skip it if your cabinet is 600 mm deep or you only have a 2-post rack.
→ Also consider the grey 691653GR.80, or a lighter front-mount shelf for small devices.
Not sure it fits your setup? Send us the model of your rack, switch or device and we will check compatibility before you order.
