EFB ET-25133.1V1 Shielded Cat.6A 2-Port RJ45 Flush Outlet, Vertical Cable Entry, RAL 9010

Brand:
EFB
EFB ET-25133.1V1 White Two-Port Shielded Cat6A Flush Data Outlet
EFB ET-25133.1V1 Shielded Cat.6A 2-Port RJ45 Flush Outlet, Vertical Cable Entry, RAL 9010
€19.65 inc. VAT
Buy
ET-25133.1V1
€16.51
€19.65 inc. VAT
Ships from EU stock: 1 item(s)
+ −
Add to wish list Ask a question
Product Code
04:263885
EAN Code
4049759151553
Manufacturer
EFB

Quick Specs

Ports
2 × RJ45
Category / bandwidth
Cat.6A / 500 MHz
Cable entry
Vertical, up/down
Finish
White RAL 9010
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

Two shielded Cat.6A outlets with vertical cable entry

2 × RJ45500 MHz50 × 50 mm plate

The EFB ET-25133.1V1 provides two shielded Cat.6A RJ45 outlets with up/down cable entry and LSA IDC termination. Its 40° outlet arrangement, white RAL 9010 central plate and supplied 80 × 80 mm frame suit compatible flush, duct or underfloor installations.

Key Features


Plan the entry direction
This variant routes installation cable vertically from above or below. Check the available cable bend space and the 40.95 mm device depth.

Shielded LSA termination
Die-cast aluminium shielding, shielded sockets, a separate 6.3 mm grounding connection and strain relief support the installed cable arrangement. Use the correct LSA termination tool.

Identify both outlets
The label field has a transparent cover and the ports have dust covers. Keep a separate cable termination for each outlet.

Technical Specifications

Network and termination
Ports 2 × RJ45 2x8(8)
Category / bandwidth Cat.6A (TIA) / 500 MHz
Standards ISO/IEC 11801; EN 50173
Listed transmission rates 1 / 2.5 / 5 / 10 Gbit
PoE support IEEE 802.3af PoE; IEEE 802.3at PoE+; IEEE 802.3bt 4PPoE
Termination Colour-coded LSA IDC terminals
Cable entry Vertical, up/down
Outlet angle 40°
Housing Fully shielded die-cast aluminium
Shield connection Clamp
RJ45 sockets Shielded
Separate grounding connection 6.3 mm
Separate strain relief Yes
Installation and physical details
Mounting Flush, duct and underfloor systems; screw fastening
Surface mounting No
Device width / height / depth 50 × 50 × 40.95 mm
Central plate 50 × 50 mm, DIN 49075
Included cover frame 80 × 80 mm
Colour White RAL 9010
Protection rating IP20
Dust covers Yes
Label field With transparent cover
Operating temperature −10 to +60 °C
Model ET-25133.1V1
EAN 4049759151553

What's in the Box

Two-port outlet with 50 × 50 mm central plate
80 × 80 mm cover frame

Frequently Asked Questions

Does it include the cover frame?
The manufacturer lists a 50 × 50 mm central plate and an included 80 × 80 mm cover frame. Check the chosen installation system before fitting.
Can I mount it directly on a flat wall surface?
The listed methods are flush, duct or underfloor installation; surface mounting is marked No. Select suitable mounting hardware for the installation.
Singular Expert Insight
Check the mounting system, vertical cable approach and bonding requirements before ordering. Cat.6A performance and PoE operation depend on the complete correctly installed link. Check the flush box, frame and cable-entry requirements

Buyer’s Guide

Buy it if

You need two shielded Cat.6A ports with vertical cable entry in a compatible installation.

Skip it if

You need left/right cable entry or a surface-mounted housing.

Also consider

Check mounting depth, cable routing and correct LSA tooling.
