| Identification |
| Brand |
Elo |
| SKU / part number |
E449111 |
| EAN / GTIN |
0843173164212 |
| Display |
| Model / regional variant |
1510L; EMEA; ET1510L-0NEA-1-BL-NS-G |
| Colour / construction |
Black; ventless rear cover and cable cover |
| Panel / aspect ratio |
15.6-inch LED-backlit active-matrix TFT LCD; 16:9 |
| Touch capability |
Non-touch; anti-glare edge-to-edge glass |
| Native resolution |
1920 × 1080 Full HD; optimal 60 Hz |
| Preset input timings |
640×480/800×600/1024×768 at 60 Hz; 1280×800 and 1366×768 at 60 Hz or 60 Hz RB; 1920×1080 at 60 Hz |
| Active display area |
344.16 × 193.59 mm |
| Typical brightness |
250 cd/m² LCD panel; 220 cd/m² with anti-glare glass |
| Typical contrast |
700:1 |
| Typical total response |
25 ms |
| Viewing angles |
170° horizontal / vertical |
| Colours |
16.2 million |
| Connections & controls |
| Digital video inputs |
HDMI 1.4 Type A; DisplayPort 1.2 (supports later DisplayPort sources) |
| Additional video input |
USB-C; Elo recommends E129019 USB-C-to-USB-C cable for compatibility |
| Input sync range |
Horizontal 30–82 kHz; vertical 60 Hz |
| Audio |
Two internal 2 W speakers |
| Rear controls |
Menu/select, down/minus, up/plus, source/exit and power buttons |
| OSD settings |
Brightness, contrast, eco mode, image ratio, colour temperature, OSD position/timeout/language, input selection, reset, information, auto adjust, volume and source hotkey |
| OSD languages / locking |
English, French, Spanish, Simplified/Traditional Chinese, Korean, Russian, Portuguese and Japanese; OSD/power lockout |
| Power |
| Power input |
External 12 V DC ±5%, included 36 W adapter; alternative USB-C power input |
| Typical power at stated brightness |
7 W at default 90%; 8.5 W at 100% |
| Sleep / off reference |
0.5 W / 0.3 W; manufacturer system measurement |
| USB-C power profiles |
5 V ±5% / 3 A; 9 V ±5% / 3 A; 15 V ±5% / 1.8 A; 20 V ±5% / 1.35 A |
| DC connector dimensions |
Monitor jack: pin Ø2.0 +0/−0.1 mm, barrel inner Ø6.4 ±0.3 mm, depth 8.8 ±0.3 mm; adapter plug: inner Ø2.1 ±0.1 mm, outer Ø5.5 ±0.05 mm, length 9.5 ±0.3 mm |
| Installation & operating limits |
| Dimensions without stand |
360.69 × 216.83 × 26.3 mm |
| Weight / shipping |
1.33 kg product; 2.57 kg packed; carton 470 × 331 × 175 mm |
| Mounting |
Four-hole VESA 75 × 75 mm; stand/mount sold separately |
| Temperature |
Operating 0–40 °C; storage −20 to 60 °C |
| Humidity |
Non-condensing: operation 20–80%; storage 10–95% |
| Impact / ESD compliance |
IK06; UL62368 ball-drop; GLI 10 kV air / 8 kV contact ESD |
| Energy / environmental compliance |
ENERGY STAR 8.0; RoHS, China RoHS, WEEE |
| Regulatory declarations |
CE/TÜV, UKCA, RCM, cUL/IC, UL/FCC, CB, CCC, VCCI, KCC, BSMI |
| Reliability reference |
Demonstrated MTBF 50,000 hours; not a guaranteed service life |
| Manufacturer term |
3-year limited manufacturer warranty; subject to Elo terms |
| Optional mounting accessories |
E143088 wall kit, E043382 shelf bracket, E045151 pole bracket, E514693 countertop / E514881 + E515260 floor stand |
