Elo 1594L / LCD monitor / 15.6" / open frame / touchscreen / 1920 x 1080 Full HD (1080p) / 350 cd/m² / 800:1 / 25 ms / HDMI, VGA, DisplayPort / black | E131375
Please sign in so that we can notify you about a reply
Product Specification
| Display Type | LCD monitor / TFT active matrix |
| Diagonal Size | 15.6" |
| Aspect Ratio | 16:9 |
| Native Resolution | Full HD (1080p) 1920 x 1080 |
| Brightness | 350 cd/m² |
| Contrast Ratio | 800:1 |
| Colour Support | 16.7 million colours |
| Response Time | 25 ms (typical) |
| Vertical Refresh Rate | 50 - 75 Hz |
| Horizontal Refresh Rate | 30 - 82 kHz |
| Horizontal Viewing Angle | 178 |
| Vertical Viewing Angle | 178 |
| OSD Languages | Chinese (traditional), Chinese (simplified), English, German, French, Italian, Spanish, Japanese |
| Features | Remote OSD, Projected Capacitive Touch (P-CAP) technology |
| Colour | Black |
| Dimensions (WxDxH) | 39.47 cm x 24.2 cm x 4.34 cm |
| Weight | 3.02 kg |
| Input | Input |
| Type | Touch-screen, remote control - touchscreen |
| Movement Detection Technology | Projected capacitive |
| Connectivity | Connectivity |
| Interfaces | HDMI (Type A) ¦ VGA (DB-15) ¦ DisplayPort 1.1a ¦ USB 2.0 |
| Mechanical | Mechanical |
| VESA Mounting Interface | 75 x 75 mm |
| Miscellaneous | Miscellaneous |
| Included Accessories | Screws, flush mount brackets |
| Cables Included | 1 x HDMI cable ¦ 1 x USB touch cable ¦ 1 x VGA cable |
| Mounting Kit | Included |
| MTBF | 50,000 hours |
| Compliant Standards | UL, TUV, BSMI, cUL, CB, CCC, IC, FCC, RoHS, KCC, WEEE, EAC, China RoHS, RCM, CoC, IK07, UL62368, Commercial Grade |
| Power | Power |
| Power Consumption (Typical) | 13.23 Watt |
| Power Consumption Sleep | 0.48 Watt |
| Power Consumption (Off Mode) | 0.22 Watt |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 47 cm |
| Shipping Depth | 33.1 cm |
| Shipping Height | 17.5 cm |
| Shipping Weight | 4.62 kg |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 20 - 80% |
Features - Elo - E131375
Resolution
1920 x XXXX
More Details
Product Code
CJ22412
EAN Code
0843173124179
Manufacturer
Elo
