Name: Elo I-Series 3 E700774 15-inch 4:3 10-Touch All-in-One, Intel Core i3-1215UL, 8GB DDR5, 128GB NVMe SSD, No OS, Stand, Black
Brand: Elo
SKU: E700774
Price: 3315.77 EUR
Availability: InStock

CODE (SKU):

E700774

€2,786.36

€3,315.77 inc. VAT

Ships from EU stock: 6 item(s)

+ −

Add to wish list Ask a question

CPU Type

Intel Core i3

Intended Use

Touchscreen

Product Code

CJ76389

EAN Code

0843173153995

Manufacturer

Elo

Features

Bluetooth, Wireless

Quick Specs

Screen / touch

15″ / 4:3 XGA / 10-touch

Processor

Intel Core i3-1215UL

Installed memory / SSD

8GB DDR5 / 128GB NVMe

OS / stand

No OS / stand included

Delivery

Order Today...

Ships...

Delivery...

ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.

Payment options

✓ Viva Wallet

✓ Revolut

✓ Bank Deposit

Secure checkout with flexible payment methods

Trusted Tech Choice

Buying Benefits Verified

Competitive EU pricing

Delivered to Cyprus from EU stock

Local warranty support

Elo I-Series 3 E700774 15-inch 4:3 10-Touch All-in-One, Intel Core i3-1215UL, 8GB DDR5, 128GB NVMe SSD, No OS, Stand, Black

15″ / 4:3 XGA / 10-touchIntel Core i3-1215UL8GB DDR5 / 128GB NVMe

This 15-inch I-Series 3 combines a 10-point anti-glare touchscreen with an Intel i3 platform for a staffed till, service desk or interactive application. Its 4:3, 1024 × 768 format suits applications designed for a square screen. The 128GB NVMe drive and 8GB DDR5 memory are the installed configuration; the stand and POS power connections are included. It is supplied without an operating system, so budget for installation and application setup.

Key Features

Use the right screen format

The square format preserves layouts designed around 4:3. Anti-glare glass helps manage reflections at the counter.

Connect POS peripherals directly

Powered USB, serial and cash-drawer ports reduce the need for separate adapters. Their voltage and power limits still need to match each peripheral.

Plan installation and maintenance

A stand, VESA mounting and replaceable memory/storage support different installations. IP54 requires sealed covers and landscape use; the power adapter is outside that rating.

Technical Specifications

Identification
Brand	Elo
SKU / part number	E700774
EAN / GTIN	0843173153995
Platform & installed configuration
Product / enclosure	I-Series 3 with Intel; black, fanless, zero-bezel touchscreen; stand included
Processor	Intel Core i3-1215UL; 10MB Smart Cache; up to 4.40GHz with Intel Turbo Boost 2.0
Installed RAM	8GB DDR5-4800 SO-DIMM; one of two slots occupied
Memory expansion	Maximum 64GB across two DDR5-4800 SO-DIMM slots; check installed module brand before buying a kit
Installed storage	128GB M.2 PCIe NVMe SSD; 80 TBW
Usable capacity	GB = one billion bytes; formatted/user-accessible capacity is lower
Operating system	No operating system installed; Linux SuSE, Ubuntu and Red Hat pretested by Elo
Graphics	Intel UHD Graphics
BIOS / security	AMI BIOS; TPM 2.0
Remote management	No Intel AMT support for this processor configuration
Clock	Replaceable CR2450 lithium-metal RTC battery
Display & touch
Panel / aspect ratio	15-inch active-matrix TFT LED LCD; 4:3
Resolution / refresh	1024 × 768 at 60Hz
Touch / surface	TouchPro projected-capacitive (PCAP), 10 simultaneous touches; anti-glare
Active display area	304.1 × 228.1 mm
Typical brightness	400 cd/m² LCD; 340 cd/m² through TouchPro PCAP
Colours	262,000
Typical total response	23 ms
Typical contrast	800:1
Viewing angles	160° horizontal / 150° vertical
Connections & peripherals
LAN	One RJ45 Gigabit Ethernet port, up to 1Gbps
Wireless	Wi-Fi 802.11a/b/g/n/ac/ax at 2.4/5/6GHz; Bluetooth 5.3
USB host ports	Four USB-A USB 3.2 Gen 1×1 (5Gbps), also described as USB 3.0
Edge Connect	Four micro-USB 2.0 ports for optional Elo Edge Connect peripherals
USB-C display output	Full-function USB-C: USB 3.0 data, DisplayPort/video output and up to 27W power
Powered USB	One 24V / 2.3A Powered USB; two 12V / 1.5A Powered USB ports
Serial	One RJ50 RS-232; optional 12V enabled in BIOS, disabled by default; RJ50-to-DB9 cable included
Cash drawer	RJ12, EPSON pinout, 12/24V; default 24V, changed in BIOS
Audio	3.5mm headset jack; two internal 2W speakers
Power & installation
Power supply	Included external 24V DC / 180W adapter; 100–240V AC, 50–60Hz input; system rating 24V / 7.5A maximum
Manufacturer operating-power reference	49W without peripherals, tested with 8GB RAM / 128GB SSD; configuration-dependent reference
Sleep / off reference	Below 5W sleep; below 0.5W off
Peripheral power budget	UM600733 reference ESY15i3C: no more than 131W combined peripherals at maximum system load; manual test uses 8GB / 128GB
Power-load limitation	Total system plus peripherals must stay within 180W. Use an external adapter for the 24V peripheral if CPU load is 100% and all other I/O ports draw their maximum power
Dimensions with stand	359.5 × 356.0 × 197.5 mm
Weight / shipping	6.7kg product; 10.26kg packed; carton 497 × 487 × 345 mm
Mounting	Stand included; VESA 75 × 75mm; 75-to-100mm adapter and screws included
Physical security / servicing	Kensington lock provision; serviceable internal components; opening the rear cover requires care to preserve IP protection
Environment & manufacturer terms
Operating / storage temperature	0–35°C operation; −20 to 60°C storage
Thermal test condition	0.5m/s airflow and CPU minimum assured power; Elo recommends its optimize-TDP tool for No OS units
Humidity	Non-condensing: 20–80% operation; 5–95% storage, maximum wet-bulb 38.7°C
Altitude	0–3,048m operation; 0–12,192m storage
Ingress protection	IP54 only in landscape with all connector/peripheral covers tightly sealed; not face-up/face-down; power brick excluded
Regulatory declarations	CE, UKCA, cUL/IC, UL/FCC, TÜV, RCM, CB, S-Mark, ANATEL, VCCI/MIC, CCC/SRRC, NOM, RoHS CoC, R-NZ
Energy certification	ENERGY STAR 8.0-certified configurations available in the family; exact SKU certification not asserted
Reliability reference	Demonstrated MTBF 50,000 hours; not a guaranteed operating life
Manufacturer warranty	3-year limited Elo warranty; static-image burn-in excluded
Optional extended services	4-year E819598; 5-year E819795; AUR options: 3-year E820186, 4-year E820388, 5-year E820582
Optional expansion
Optional customer displays / cables	10-inch touch E045337 / non-touch E138394; 13-inch touch E683595; Elo USB-C cables E710364 (6ft) / E969524 (2ft)
Optional Edge Connect peripherals	MSR E001002; VFD E001003; fingerprint E134286; webcam E201494; 3D camera E134699; status light E644767; barcode E384627/E245047/E393160; RFID E673037; EMV cradles E375343/E710930/E586981
Manufacturer-qualified memory / storage kits	DDR5 kits E466053 8GB / E466237 16GB / E466430 32GB (5600MHz kit rating, not a promised system speed); NVMe E466613 128GB / E466803 256GB

What's in the Box

I-Series 3 touch computer with stand

180W adapter, North American and European mains cords

RJ50-to-DB9 serial cable, quick installation guide and cable tie

Customer-display mounting screw, VESA screws, VESA cover and screw

75-to-100mm VESA adapter and mounting screw

What Will Not Work

Peripheral devices, customer display and Kensington lock are separate purchases.

IP54 does not apply in portrait, face-up or face-down orientation, or to the power brick.

Frequently Asked Questions

Which operating system is included?

None is installed. Elo lists Linux SuSE, Ubuntu and Red Hat as pretested options; confirm the distribution, drivers and application before deployment.

Will the screen fit my application layout?

This is a 15-inch 4:3 screen at 1024 × 768, not a Full HD wide model. Check that your application supports this resolution.

Can it power a customer display and POS devices?

Yes, through suitable ports and within their limits. USB-C provides up to 27W; Powered USB and the 12/24V drawer connection have separate limits. Check pinout, voltage and the total 180W system budget before connecting equipment.

Singular Expert Insight

Match the processor and operating system to the POS software first, then check screen layout and peripheral power. The integrated ports are useful only when the drawer pinout and device voltages match. Keep space for cable access and the specified cooling airflow. Compare the simpler E-Series 3 POS platform

Buyer’s Guide

Buy it if

You need a complete touch computer with a stand and dedicated POS connections.

Skip it if

You need a battery-powered terminal, an outdoor display or a different application-certified operating system.

Also consider

Compatible customer displays, scanners and a verified cash drawer; accessories are optional.
