Equip 769403 USB-C Keystone Coupler Female to Female USB 3.2 Gen 2 20Gbps 100W Power Delivery 4K 60Hz Tool-Free White
Brand:
Equip
Equip 769403 USB-C Keystone Coupler Female to Female USB 3.2 Gen 2 20Gbps 100W Power Delivery 4K 60Hz Tool-Free White
€5.85 inc. VAT
769403
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Equip 769403 — USB 3.2 Gen 2 USB-C Keystone Coupler, 20 Gbps, 100 W PD, 4K/60Hz, White
USB-C female to femaleUp to 20 Gbps100 W Power Delivery pass-through4K/60Hz DP Alt Mode · white
The Equip 769403 is a white USB-C female-to-female keystone coupler that lets installers bring a full-feature USB-C port to a wall plate, surface-mount box or patch panel: it passes USB 3.2 Gen 2 data at up to 20 Gbps, 100 W (20 V / 5 A) USB Power Delivery and 4K/60Hz video over DisplayPort Alt Mode or Thunderbolt-compatible hosts through a single keystone opening. The tool-free snap-in module measures 28.8 × 17.2 × 19.2 mm, weighs 7 g and matches standard white faceplates; the same module in black is the 769404. Part number 769403, EAN 4015867244159. Typically in stock with fast delivery across Cyprus.
Compatibility — check before buying:
Passive coupler — it only joins two USB-C cables; the data rate, wattage and video you get are set by the host, the device and the cables on each side (use full-featured USB-C cables rated for the speed and wattage you need). Adding a coupler adds a connector pair to the link, so keep total cable length short for 20 Gbps and 4K/60. Video requires a host with DP Alt Mode or Thunderbolt. Equip lists the module as unshielded. Fits standard keystone wall plates, surface boxes and patch panels — check the cut-out size on non-standard faceplates.
Best For
✓ Meeting rooms and huddle spaces with a USB-C table or wall port
✓ Hot desks where the monitor and charger are wired into the wall
✓ Classrooms and lecterns with white faceplates
✓ Patch panels in AV racks
✓ Clean cable management in reception and retail counters
✓ Structured cabling installers standardising on keystone
Key Features
Data, power and video through one keystone
Carries USB 3.2 Gen 2 data at up to 20 Gbps, 100 W (20 V / 5 A) Power Delivery and 4K/60Hz DisplayPort Alt Mode video, so a single wall port can charge a laptop, drive a display and connect peripherals.
Tool-free keystone installation
Snaps into any standard keystone opening in a wall plate, surface-mount box or patch panel without tools, keeping the USB-C connection tidy and protected behind the faceplate instead of dangling from a cable.
Compact white module
28.8 × 17.2 × 19.2 mm, 7 g, white plastic housing that matches the white faceplates used in most offices and classrooms. RoHS compliant. Black version: Equip 769404.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
USB-C is increasingly the one cable on the meeting-room table, and the 769403 is how you get it into the wall without cutting a custom plate: a keystone module that passes 20 Gbps, 100 W and 4K/60 rather than the USB 2.0-only couplers that used to fill that slot. Treat it as a link in a chain — the cables on either side decide what actually arrives. Pair it with a USB-C monitor from our PC monitors range or a docking station behind the wall for a clean single-cable desk.
Buyer’s Guide
Buy it if
You are wiring USB-C into white wall plates, table boxes or patch panels and want one keystone module that carries data, 100 W charging and 4K/60 video instead of a data-only coupler.
Skip it if
You need a shielded module, 40 Gbps Thunderbolt/USB4 throughput, a black module (769404), or a simple desk extension — a USB-C extension cable is cheaper there.
Also consider
Equip 769404 (same coupler in black), Equip USB-C cables rated for 20 Gbps / 100 W for each side, and an Equip keystone wall plate or surface-mount box to house it.
Features - Equip - 769403
Colour
white
More Details
Product Code
04:581648
EAN Code
4015867244159
Manufacturer
Equip
