Ricoh (Fujitsu) Consumable Kit 3740-500K, 2 Pick Rollers and 2 Brake Rollers, up to 500,000 Scans, for fi-7600, fi-7700, fi-7700S
Brand:
Fujitsu
Ricoh (Fujitsu) Consumable Kit 3740-500K, 2 Pick Rollers and 2 Brake Rollers, up to 500,000 Scans, for fi-7600, fi-7700, fi-7700S
€463.79 inc. VAT
CON-3740-500K
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Ricoh (Fujitsu) Consumable Kit 3740-500K — two roller changes for the fi-7600 and fi-7700 production scanners
Genuine PFU/RicohUp to 500,000 scans2 replacement cyclesfi-7600 / fi-7700
The Ricoh (Fujitsu) Consumable Kit 3740-500K contains two pick rollers and two brake rollers for the fi-7600, fi-7700 and fi-7700S production document scanners, covering up to 500,000 scans — two full roller replacement cycles.
These rollers separate and feed each sheet from the 300-sheet hopper. When they wear, double-feeds, skewed pages and pick failures increase. The scanner counts sheets and reports when the rollers are due.
Before you order: Kit 3740-500K is for the fi-7600, fi-7700 and fi-7700S only. Departmental fi-7100/fi-7200 models use kit 3670-400K, the fi-7460/fi-7480 use kit 3710-400K, and fi-7800/fi-7900 use different PA03575 parts.
What's in the Box
- 2 x Pick roller (PA03740-K011)
- 2 x Brake roller (PA03740-K010)
What It Means in Practice
- Each roller is rated for 250,000 sheets or one year, whichever comes first, per the fi-7700 datasheet.
- The kit therefore covers two full changes — up to 500,000 scans.
- Change the pick and brake rollers together and reset both counters in the Software Operation Panel.
- At high daily volumes the one-year limit is rarely the deciding factor; at low volumes it is.
What Will Not Work
- It does not fit the fi-7100/fi-7200 series (3670-400K) or fi-7460/fi-7480 (3710-400K).
- It does not fit the fi-7800 or fi-7900.
- It contains no cleaning fluid or cloths — use the F1 cleaning kit CON-CLE-K75.
- It will not fix image streaks caused by dirty glass or sensors.
Key Features
Two full cycles
Up to 500,000 scans from one box.
250,000-sheet rollers
Each roller rated for 250,000 sheets or one year.
Production-scanner fit
Built for the fi-7600, fi-7700 and fi-7700S feeders.
Separate counters
Pick and brake roller counts tracked in the Software Operation Panel.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
On fi-7600 and fi-7700 scanning stations, roller wear is the main cause of feeding problems in long batch runs. Having the second set ready means the swap happens at the next counter warning, not after a day of misfeeds. See our printer accessories and service parts for cleaning supplies.
✓ Buy it if you run an fi-7600, fi-7700 or fi-7700S and the roller counters are close to 250,000 sheets.
✕ Skip it if your scanner is from the fi-7100/7200, fi-7460/7480 or fi-7800/7900 range.
→ Also consider Ricoh (Fujitsu) F1 cleaning kit CON-CLE-K75, officially listed for the fi-7600 and fi-7700.
Not sure which kit your scanner takes? Send us the model from the scanner label and we will check it before you order.
Features - Fujitsu - CON-3740-500K
More Details
Product Code
CH01589
EAN Code
5032140202018
Manufacturer
Fujitsu
