Gigabyte B840M EAGLE WIFI6 micro ATX Motherboard | AMD B840 | Socket AM5 | DDR5

Brand:
GigaByte
Gigabyte B840M EAGLE WIFI6 AMD B840 mATX DDR5
Gigabyte B840M EAGLE WIFI6 micro ATX Motherboard | AMD B840 | Socket AM5 | DDR5
€167.75 inc. VAT
Buy
B840M EAGLE WIFI6
€140.97 €156.63
€167.75 inc. VAT
Ships from EU stock: 11 item(s)
+ −
Add to wish list Ask a question
Product Code
04:568220
EAN Code
4719331868970
Manufacturer
GigaByte

Quick Specs

Interfaces
2 x USB 3.2 Gen 1 4 x USB 2.0 1 x audio line-out - mini-jack 1 x microphone - mini-jack 1 x audio line-in - mini-jack 2 x aerial 1 x LAN (2.5Gigabit Ethernet) 1 x PS/2 keyboard / mouse 1 x HDMI 1 x DisplayPort
Product Type
HD Audio (8-channel)
Compatible Processors
Ryzen 7000 / 8000 / 9000 Series
Chipset
AMD B840
CPU Socket
Socket AM5
Memory Speed
2200 MHz to 3800 MHz (O.C.)
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Singular Selected

Gigabyte B840M EAGLE WIFI6 micro ATX Motherboard | AMD B840 | Socket AM5 | DDR5

The Gigabyte B840M EAGLE WIFI6 is a micro ATX motherboard for AMD Socket AM5 builds using Ryzen 7000, 8000 or 9000 Series processors. It pairs DDR5 support with Wi-Fi 6, Bluetooth 5.3, 2.5 Gigabit Ethernet and PCIe 4.0 and M.2 connectivity for a balanced desktop platform.
2 x USB 3.2 Gen 1 4 x USB 2.0 1 x audio line-out - mini-jack 1 x microphone - mini-jack 1 x audio line-in - mini-jack 2 x aerial 1 x LAN (2.5Gigabit Ethernet) 1 x PS/2 keyboard / mouse 1 x HDMI 1 x DisplayPort HD Audio (8-channel) Ryzen 7000 / 8000 / 9000 Series AMD B840

The Gigabyte B840M EAGLE WIFI6 is a micro ATX motherboard for AMD Socket AM5 builds using Ryzen 7000, 8000 or 9000 Series processors. It pairs DDR5 support with Wi-Fi 6, Bluetooth 5.3, 2.5 Gigabit Ethernet and PCIe 4.0 and M.2 connectivity for a balanced desktop platform.

Best For
✓ Suitable for builders who want an AMD AM5 micro ATX motherboard with DDR5, onboard Wi-Fi 6
✓ 2.5GbE for a compact but capable desktop build

Key Features


Commercial Fit
The main draw is the mix of AM5 support, DDR5, wireless networking and practical expansion in a micro ATX format, making it a solid foundation for a modern Ryzen system.

Compatible Processors
Compatible Processors: Ryzen 7000 / 8000 / 9000 Series

Chipset
Chipset: AMD B840

CPU Socket
CPU Socket: Socket AM5

Technical Specifications

Product Type Motherboard - micro ATX | HD Audio (8-channel)
Chipset AMD B840
CPU Socket Socket AM5
Compatible Processors Ryzen 7000 / 8000 / 9000 Series
Memory Support DDR5 | Dual channel | Non-ECC | Unbuffered | Up to 128 GB
Memory Speed 2200 MHz to 3800 MHz (O.C.)
Integrated Audio HD Audio (8-channel)
Network Wi-Fi 6 (802.11ax) | Bluetooth 5.3 | 2.5 Gigabit Ethernet
Expansion Slots 1 x PCIe 4.0 x16 | 1 x PCIe 3.0 x4 | 2 x M.2 slots
Storage Interfaces 4 x SATA-600 ports | 2 x M.2 connectors | RAID 0 / 1 / 5 / 10
Rear Interfaces 2 x USB 3.2 Gen 1 | 4 x USB 2.0 | HDMI | DisplayPort | 2.5 Gigabit Ethernet | PS/2 keyboard / mouse | audio line-out | microphone | audio line-in
Internal Headers USB-C 3.2 Gen 1 header | 2 x USB 3.2 Gen 1 headers | 4 x USB 2.0 headers | audio header | SPI header
Power Connectors 24-pin main power connector | 8-pin ATX12V connector
BIOS AMI | UEFI BIOS
Hardware Features Q-Flash Plus | Q-Flash | GIGABYTE Smart Fan 6 | RGB FUSION | M.2 Thermal Guard III | pre-mounted I/O shield
Hardware Monitoring System voltage | temperature detection | fan speed detection | water cooling flow rate | fan fail warning
Included Accessories M.2 SSD thick/thin rubber pad | 2 aerials
Included Cables 2 x Serial ATA cable
Dimensions 24.4 cm x 24.4 cm
Interfaces 2 x USB 3.2 Gen 1 4 x USB 2.0 1 x audio line-out - mini-jack 1 x microphone - mini-jack 1 x audio line-in - mini-jack 2 x aerial 1 x LAN (2.5Gigabit Ethernet) 1 x PS/2 keyboard / mouse 1 x HDMI 1 x DisplayPort
Package Contents M.2 SSD thick/thin rubber pad, 2 aerials
SKU / EAN B840M EAGLE WIFI6 | 4719331868970

Frequently Asked Questions

What should I know before buying?
This board is for AM5 Ryzen 7000, 8000 or 9000 Series processors and uses DDR5 memory. Check your case size, CPU choice and storage plan before building.
What connectivity does it offer?
4 x SATA-600 ports | 2 x M.2 connectors | RAID 0 / 1 / 5 / 10
What is included in the box?
M.2 SSD thick/thin rubber pad | 2 aerials
Singular Expert Insight
The main draw is the mix of AM5 support, DDR5, wireless networking and practical expansion in a micro ATX format, making it a solid foundation for a modern Ryzen system.

Buyer’s Guide

Buy it if
Suitable for builders who want an AMD AM5 micro ATX motherboard with DDR5, onboard Wi-Fi 6 and 2.5GbE for a compact but capable desktop build.
Skip it if
This board is for AM5 Ryzen 7000, 8000 or 9000 Series processors and uses DDR5 memory. Check your case size, CPU choice and storage plan before building.

Features - GigaByte - B840M EAGLE WIFI6

CPU Socket
  • Socket AM5
More Details
Product Code
04:568220
EAN Code
4719331868970
Manufacturer
GigaByte
