HPE Aruba Instant On 1960 12XGT 4SFP+ Switch / Switch / Managed / 12 x 100/1000/10000 + 4 x 10 Gigabit SFP+ / rack-mountable / BTO | JL805A
Please sign in so that we can notify you about a reply
Special Features
- Simplify network management by stacking up to (four) 4 Aruba Instant On 1960 switches and managing them through one single IP address; stacking supported via local and cloud-managed stacking modes
- For environments with heavy bandwidth needs, 10GBase-T and SFP+ uplink ports deliver lightning-fast network speeds and nearly eliminates traffic bottlenecks
- Aruba Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely
Product Specification
| Device Type | Switch - 12 ports - Managed |
| Enclosure Type | Rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Ports | 12 x 100/1000/10000 + 4 x 10 Gigabit SFP+ |
| Performance | Throughput: 238 Mpps ¦ Switching capacity: 320 Gbps ¦ Latency (100 Mbps): 7.4 µs ¦ Latency (1 Gbps): 4.2 µs ¦ Latency (10 Gbps): 1.1 µs |
| Capacity | MAC address entries: 16000 ¦ IPv4 routes (static): 512 ¦ IPv6 routes (static): 512 |
| MAC Address Table Size | 16000 entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | Static IP routing |
| Remote Management Protocol | SNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS, RADIUS |
| Authentication Method | RADIUS |
| Features | Flow control, DHCP support, auto-negotiation, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), port mirroring, IPv6 support, half duplex mode, full duplex mode, Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Trusted Platform Module (TPM), Link Aggregation Control Protocol (LACP), Class of Service (CoS), Energy-Efficient Ethernet (EEE), BPDU Filter, auto voice VLAN, Media Endpoint Discovery (LLDP-MED) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1s, IEEE 802.1ab (LLDP) |
| Processor | 1 x ARM: 2 GHz |
| Status Indicators | Port status, power |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 12 x 10/100/1000 Base-T RJ-45 ¦ 4 x 10 Gigabit Ethernet / 10 Gigabit Ethernet SFP+ SFP+ |
| Power | Power |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Miscellaneous | Miscellaneous |
| MTBF | 88.8 years |
| Compliant Standards | EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, EN 61000-3-3, ICES-003 Class A, VCCI Class A, CNS 13438 Class A, KN35, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, AS/NZS CISPR 32 Class A, KN32 Class A, IEC/EN 61000-4-11, IEC/EN 61000-4-2, UL 62368-1 Second Edition, IEC/EN60950-1:2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013, EN 55032:2015 Class A, CISPR 32:2015 Class A, UL 62368-1, EN 55035, CISPR 35, IEC/EN 60825-1:2014 Class 2, IEC/EN 62368-1, UL 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1 Second Edition, FCC CFR47 Part 15 B Class A 2018 |
| Pricing Type | BTO |
| Dimensions & Weight | Dimensions & Weight |
| Width | 44.25 cm |
| Depth | 35.05 cm |
| Height | 4.395 cm |
| Weight | 4.3 kg |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 15 - 95% (40 °C) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
Features - Hewlett Packard - JL805A#ABB
More Details
Product Code
07:125633
EAN Code
0190017521770
Manufacturer
Hewlett Packard
