HPE Aruba Networking CX 8325H 4-Post Rack Mount Shelf Kit, Tray for One or Two Half-Width 8325H Switches
Brand:
Hewlett Packard
HPE Aruba Networking CX 8325H 4-Post Rack Mount Shelf Kit, Tray for One or Two Half-Width 8325H Switches
€1515.51 inc. VAT
S2T43A
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
HPE Aruba Networking CX 8325H 4-Post Rack Mount Shelf Kit
HPE S2T43ACX 8325H only1 or 2 half-width switchesPair with J9583B
The HPE Aruba Networking CX 8325H 4-post Rack Mount Shelf Kit (S2T43A) is the tray that mounts one or two half-width Aruba CX 8325H switches side by side in a four-post 19-inch rack or cabinet. It is for data-centre and campus-core teams deploying the 8325H, which is a half-width switch and ships without rack-mount brackets.
HPE's 8325H installation guide specifies that this tray must be paired with the Aruba X414 1U Universal 4-post Rack Mount Kit (J9583B): the tray holds the switches, the J9583B provides the four-post rail mounting. The switches slide into the tray and lock with a latch, and power cord retention clips keep the power cables in place.
Before you order: This tray must be ordered together with the Aruba X414 1U Universal 4-post Rack Mount Kit (J9583B). On its own it cannot be fixed into a four-post rack. For two-post racks HPE offers a different kit, S2T44A.
What's in the Box
- Rack mount tray for one or two half-width CX 8325H switches
- The four-post rail kit is not included — order Aruba X414 J9583B with it
- The 8325H switches are not included
What It Means in Practice
- Two half-width 8325H switches fit side by side in one tray, so a redundant pair shares the same rack position.
- If only one switch is installed, HPE offers a blank panel (S5D79A) to fill the empty tray slot.
- The switch measures 8.27 × 22.70 × 1.69 in (W × D × H), so plan rack depth for a deep 1U device and its cabling.
- Check airflow direction: 8325H models come in front-to-back and back-to-front versions, and HPE recommends positioning them to avoid recirculating hot air.
What Will Not Work
- Any switch other than the Aruba CX 8325H series.
- Mounting in a four-post rack without the J9583B rail kit.
- Two-post racks — use the HPE Aruba Networking 8325H 2-post Rack Mount Kit (S2T44A) instead.
- Full-width switches — the tray is designed for half-width 8325H units.
Key Features
Side-by-side mounting
Holds one or up to two 8325H half-width switches in a four-post rack.
Latch retention
Switches slide in and lock with a latch; power cord retention clips secure the cables.
Blank panel option
Empty slot can be closed with S5D79A.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
The 8325H is half-width, so racking it is always a two-part order: this tray plus the J9583B four-post rails, or the S2T44A kit for two-post racks. Ordering both parts together avoids a switch sitting on a shelf waiting for hardware. See our network switches for the switches themselves.
✓ Buy it if you are installing one or two Aruba CX 8325H switches in a four-post rack and are also ordering J9583B.
✕ Skip it if your rack is two-post (use S2T44A) or your switch is not an 8325H.
→ Also consider Aruba X414 J9583B (required), and S5D79A blank panel if you install a single switch.
Not sure which parts you need? Send us your 8325H SKU and rack type and we will list the exact mounting parts.
Features - Hewlett Packard - S2T43A
More Details
Product Code
CO04103
EAN Code
0190017699615
Manufacturer
Hewlett Packard
