Intel Core i5 10400 / 2.9 GHz / 6-core / 12 threads / 12 MB cache / LGA1200 Socket / OEM | CM8070104290715

Product Specification

Product Type	Processor
Type / Form Factor	Intel Core i5 10400 (10th Gen)
Number of Cores	6-core
Number of Threads	12 threads
Cache	12 MB
Cache Memory Details	Smart Cache - 12 MB
Processor Qty	1
Clock Speed	2.9 GHz
Max Turbo Speed	4.3 GHz
Bus Speed	8 GT/s
Compatible Processor Socket	LGA1200 Socket
Manufacturing Process	14 nm
Thermal Design Power	65 W
Thermal Specification	100 °C
PCI Express Revision	3.0
PCI Express Configurations	1x16, 2x8, 1x8+2x4
PCI Express Lanes Qty	16
Architecture Features	Enhanced SpeedStep technology, Hyper-Threading Technology, Execute Disable Bit capability, Intel Virtualization Technology, Intel 64 Technology, streaming SIMD extensions 4.1, streaming SIMD extensions 4.2, Intel Turbo Boost Technology 2.0, Intel AES New Instructions (AES-NI), Thermal Monitoring Technologies, Intel Virtualization Technology for Directed I/O (VT-d), Idle States, Intel VT-x with Extended Page Tables (EPT), Intel Identity Protection Technology, Intel Secure Key, Intel Advanced Vector Extensions 2 (AVX2.0), Intel OS Guard, Intel Software Guard Extensions (SGX), Intel Optane Memory Supported, Intel Boot Guard
Type	Intel UHD Graphics 630
Base Frequency	350 MHz
Max Dynamic Frequency	1.1 GHz
Max Supported Memory Size	64 GB
Max Supported Resolution	4096x2304@60Hz (eDP), 4096x2304@60Hz (DP), 4096x2160@30Hz (HDMI)
Features	Intel Clear Video Technology, Intel Clear Video HD Technology, InTRU 3D Technology, Intel Quick Sync Video, Triple Display Capable
Package Type	OEM/tray
Service & Support	Limited warranty - 3 years
