Intellinet Spare 19" Mounting Rails 12U for Intellinet Flat-Pack Wall Cabinets, 2-Piece Set, Steel, Up to 1.5 mm

The Intellinet 712453 is a set of two spare 19-inch mounting rails, 12U high, for Intellinet flat-packed 12U wall-mount cabinets (711869, 711876, 711883, 711890). Fitted at the rear, they add a second pair of rails to the two front rails that come with the cabinet, so heavier or deeper devices can be fixed at four points instead of hanging on their front ears only.

The rails are made from steel up to 1.5 mm thick with an antistatic powder coat and measure 602 x 31 x 21 mm each. They are also the right part if an original cabinet rail has been bent or lost.

• 2 × spare 19-inch mounting rails, 12U (left and right)
• Screws and cage nuts are not listed in the manufacturer scope of delivery — use the cabinet installation set

• Turns a 2-rail wall cabinet into a 4-point cabinet, so switches, small servers or rack UPS units with rear brackets are supported front and back.
• Lets you mount a 19-inch shelf at both ends for heavier non-rack devices.
• Replaces a damaged or missing original rail without replacing the cabinet.
• Order one set per cabinet — each set contains a left and a right rail.

• Cabinets of a different height — 12U rails only fit 12U cabinets.
• Other brands or Intellinet cabinets not listed above, unless we confirm the hole pattern.
• Floor-standing racks — these are wall-cabinet rails.
