Intellinet 561808 PoE-Powered 5-Port Gigabit Switch - PoE Passthrough
The Intellinet 561808 is a desktop 5-port Gigabit Ethernet switch with PoE+ support and PoE passthrough. It is designed to take power from a PoE switch or injector and pass data and electrical power to compatible devices over Cat5e or Cat6 cabling. With a metal housing and compact footprint, it suits small network installations that need straightforward PoE connectivity.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Type | Switch - 5 ports |
| Enclosure Type | Desktop |
| Subtype | Gigabit Ethernet |
| Ports | 4 x 10/100/1000 (PoE+) | 1 x 10/100/1000 (PoE Passthrough) |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 65 W |
| Performance | Packet filter throughput: 1488000 pps | Backplane speed: 10 Gbps |
| MAC Address Table Size | 2048 entries |
| Features | Flow control | full duplex mode | 1MB packet buffer | store and forward | metal housing |
| Compliant Standards | IEEE 802.3bt | IEEE 802.3af | IEEE 802.3at | IEEE 802.3 | IEEE 802.3u | IEEE 802.3ab | IEEE 802.3x |
| Status Indicators | Power | PoE | link/activity |
| Interfaces | 4 x 1000Base-T RJ-45 PoE+ - 30 W | 1 x 1000Base-T RJ-45 PoE Passthrough | 4 x 1000Base-T RJ-45 PoE+ - 30 W 1 x 1000Base-T RJ-45 PoE Passthrough |
| Power Device | External power adapter |
| Power Provided | 54.5 V - 1.32 A |
| Voltage Required | AC 100-240 V (50 - 60 Hz) |
| Power Consumption Operational | 72 Watt |
| Included Accessories | 4 rubber feet |
| Width | 16.8 cm |
| Depth | 9.3 cm |
| Height | 3.2 cm |
| Weight | 400 g |
| Shipping Weight | 900 g |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | 0 °C |
| Max Storage Temperature | 70 °C |
| Manufacturer ID | 561808 |
| EAN/UPC | 0766623561808 |
| Power | External power adapter |
| Package Contents | 4 rubber feet |
| SKU / EAN | 561808 | 0766623561808 |
SINGULAR RECOMMENDS
For who
For small offices or installers needing a compact desktop Gigabit switch with PoE+ on four ports and one PoE passthrough port.
Real reason to buy it
It combines PoE+ switching and PoE passthrough in one compact unit, with a 65 W PoE budget and Gigabit connectivity.
Know before
The unit uses an external power adapter and includes four rubber feet. Its compatibility note states it is designed for PoE-compatible devices over Cat5e or Cat6 cabling.
