j5create JCA374 / Docking station / USB-C 3.1 / HDMI / GigE | JCA374-N
Please sign in so that we can notify you about a reply
Product Specification
| Product Type | Docking station |
| Width | 5.05 cm |
| Depth | 9.65 cm |
| Height | 1.5 cm |
| Weight | 69 g |
| Enclosure Colour | Champagne metallic |
| Video | Video |
| Max Resolution Details | 3840 x 2160 - 30 Hz ¦ 1920 x 1080 - 60 Hz |
| Networking | Networking |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 2 x USB 3.1 - 9 pin USB Type A ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x USB-C with Power Delivery (60 W) - 24 pin USB-C |
| Miscellaneous | Miscellaneous |
| Cables Included | 1 x USB-C cable - integrated - 10 cm |
| Features | Surge protection, aluminum enclosure, bus powered, self-powered, DisplayPort Alt Mode, 60W power delivery (pass-through) |
| Compliant Standards | USB Power Delivery 2.0, DisplayPort 1.2, USB Power Delivery 3.0 |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 2 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 37 °C |
Features - J5CREATE - JCA374-N
More Details
Product Code
CE58413
EAN Code
4712795081039
Manufacturer
J5CREATE
