Kingston ValueRAM / DDR4 / module / 8 GB / DIMM 288-pin / 3200 MHz / PC4-25600 / CL22 / 1.2 V / unbuffered / non-ECC | KVR32N22S6/8
Please sign in so that we can notify you about a reply
Kingston ValueRAM / DDR4 / module / 8 GB / DIMM 288-pin / 3200 MHz / PC4-25600 / CL22 / 1.2 V / unbuffered / non-ECC | KVR32N22S6/8
Product Specification
| Capacity | 8 GB |
| Upgrade Type | Generic |
| Width | 133 mm |
| Height | 31.3 mm |
| Type | DRAM memory module |
| Technology | DDR4 SDRAM |
| Form Factor | DIMM 288-pin |
| Module Height (inch) | 1.23 |
| Speed | 3200 MHz (PC4-25600) |
| Latency Timings | CL22 (22-22-22) |
| Data Integrity Check | Non-ECC |
| Features | Single rank, On-Die Termination (ODT), Serial Presence Detect (SPD), sixteen banks, Low-power auto self refresh (LPASR), unbuffered |
| Module Configuration | 1024 x 64 |
| Chips Organization | 1024 x 16 |
| Voltage | 1.2 V |
| Lead Plating | Gold |
| Compliant Standards | RoHS, halogen-free, JEDEC |
| Service & Support | Limited lifetime warranty (Russia - 10 years) |
Features - Kingston - KVR32N22S6/8
More Details
Product Code
07:123397
EAN Code
0740617310870
Manufacturer
Kingston
