Lenovo ThinkSystem S4620 / SSD / Mixed Use / 1.92 TB / hot-swap / 2.5" / SATA 6Gb/s | 4XB7A17127

Lenovo ThinkSystem S4620 - SSD - Mixed Use - 1.92 TB | 4XB7A17127

Description
Features
Reviews

Special Features

Cost-effective Intel 3D NAND TLC Flash Memory
SATA TLC solid-state drive with high read performance and consistently low latencies to fulfill client needs in the enterprise space
High reliability and enhanced ruggedness
Energy savings, with typical write power consumption as low as 2.3 W per drive
Absence of moving parts to reduce potential failure points in the server
S.M.A.R.T. support
Advanced Encrypting Standard (AES) 256-bit encryption
Full end-to-end data path protection
Thermal throttling to extend the life of the drive
Enhanced power loss data protection

Product Specification

Device Type	Solid state drive - hot-swap
Capacity	1.92 TB
NAND Flash Memory Type	3D triple-level cell (TLC)
Form Factor	2.5"
Interface	SATA 6Gb/s
Features	End-to-end data protection, power loss data protection, S.M.A.R.T.
Width	70 mm
Depth	100 mm
Height	7 mm
Weight	70 g
Performance	Performance
Drive Writes Per Day (DWPD)	4
SSD Endurance	14 PB
Drive Class	Mixed Use
Drive Transfer Rate	600 MBps (external)
Internal Data Rate	550 MBps (read) / 510 MBps (write)
4KB Random Read	85000 IOPS
4KB Random Write	55000 IOPS
Average Latency	36 Âµs
Reliability	Reliability
MTBF	2,000,000 hours
Non-Recoverable Errors	1 per 10^17
Expansion & Connectivity	Expansion & Connectivity
Interfaces	1 x SATA 6 Gb/s
Compatible Bay	2.5"
Miscellaneous	Miscellaneous
Compliant Standards	VCCI, ICES-003, UL 60950-1, CSA C22.2 No. 60950-1-07, CNS 13438, RoHS 2011/65/EU, EN55022:2006, AS/NZS CISPR22:2009+A1:2010, WEEE 2012/19/EU, EMC 2014/30/EU, LVD 2014/35/EU, EN 55032:2012, KCC Article 11.1, AS/NZS CISPR 32:2015, EN 55035:2017, FCC Title 47
Pricing Type	Customer-replaceable Unit (CRU)
Dimensions & Weight (Shipping)	Dimensions & Weight (Shipping)
Shipping Width	17.4 cm
Shipping Depth	13.3 cm
Shipping Height	6.3 cm
Shipping Weight	434 g
Manufacturer Warranty	Manufacturer Warranty
Service & Support	Limited warranty - replacement - 1 year
Environmental Parameters	Environmental Parameters
Min Operating Temperature	0 Â°C
Max Operating Temperature	70 Â°C
Humidity Range Operating	5 - 95% (non-condensing)
Shock Tolerance (operating)	1000 g @ 0.5 ms
Shock Tolerance (non-operating)	1000 g @ 0.5 ms
Vibration Tolerance (operating)	2.17 g @ 5-700 Hz
Vibration Tolerance (non-operating)	3.13 g @ 5-800 Hz
Compatibility Information	Compatibility Information
Designed For	Lenovo ThinkAgile VX3530-G Appliance 7Z63 (2.5") Â¦ Lenovo ThinkAgile VX7530 Appliance 7Z63 (2.5") Â¦ Lenovo ThinkAgile VX7531 Certified Node 7Z63 (2.5") Â¦ Lenovo ThinkSystem SD530 7X21 (2.5") Â¦ Lenovo ThinkSystem SN550 7X16 (2.5") Â¦ Lenovo ThinkSystem SN850 7X15 (2.5") Â¦ Lenovo ThinkSystem SR530 7X07 (2.5"), 7X08 (2.5") Â¦ Lenovo ThinkSystem SR550 7X03 (2.5"), 7X04 (2.5") Â¦ Lenovo ThinkSystem SR570 7Y02 (2.5"), 7Y03 (2.5") Â¦ Lenovo ThinkSystem SR590 7X98 (2.5"), 7X99 (2.5") Â¦ Lenovo ThinkSystem SR630 7X01 (2.5"), 7X02 (2.5") Â¦ Lenovo ThinkSystem SR635 7Y98 (2.5"), 7Y99 (2.5") Â¦ Lenovo ThinkSystem SR645 7D2X (2.5"), 7D2Y (2.5") Â¦ Lenovo ThinkSystem SR650 7X05 (2.5"), 7X06 (2.5") Â¦ Lenovo ThinkSystem SR650 V2 7D15 (2.5") Â¦ Lenovo ThinkSystem SR655 7Y00 (2.5"), 7Z01 (2.5") Â¦ Lenovo ThinkSystem SR665 7D2V (2.5"), 7D2W (2.5") Â¦ Lenovo ThinkSystem SR850 V2 7D31 (2.5"), 7D32 (2.5") Â¦ Lenovo ThinkSystem SR860 7X69 (2.5"), 7X70 (2.5") Â¦ Lenovo ThinkSystem SR860 V2 7Z59 (2.5"), 7Z60 (2.5") Â¦ Lenovo ThinkSystem SR950 7X11 (2.5"), 7X12 (2.5") Â¦ Lenovo ThinkSystem ST550 7X09 (2.5"), 7X10 (2.5")
