Lenovo ThinkSystem B540i-2i - Storage controller (RAID) - 2 Channel - RAID RAID 0, 1, JBOD - PCIe 4.0 x2 | 4Y37A90063
Brand:
Lenovo
4Y37A90063
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Product Features
- Enhanced security
With Self-Encrypting Drive (SED) support, the Lenovo ThinkSystem B540i-2i storage controller ensures your data is secure, providing an added layer of protection against unauthorized access. - Versatile storage options
Supporting both disk array (RAID) and solid state drive configurations, this storage controller offers flexible storage solutions to meet diverse needs, ensuring optimal performance for various applications. - High-speed connectivity
Equipped with a PCIe 4.0 x2 host bus, the Lenovo ThinkSystem B540i-2i offers fast data transfer rates, enhancing overall system efficiency and performance.
Special Fetures
- Supports RAID 0, RAID 1, and JBOD for flexible storage configurations
- Features 2 M.2 card slots for expanded storage capacity
- Compliant with UEFI standards for reliable system compatibility
- Powered by Broadcom SAS3808N processor for high-performance storage management
Product Specification
| Device Type | Storage controller (RAID) - internal |
| Host Bus | PCIe 4.0 x2 |
| Storage Controller | |
| Supported Devices | Disk array (RAID), solid state drive |
| Channel Qty | 2 |
| RAID Level | RAID 0, RAID 1, JBOD |
| Processor | Broadcom SAS3808N |
| Expansion / Connectivity | |
| Interfaces | 2 x M.2 Card |
| Miscellaneous | |
| Features | Self-Encrypting Drive (SED) support |
| Compliant Standards | UEFI |
| Software / System Requirements | |
| OS Required | Red Hat Linux Enterprise Server 6 x64 Edition, Microsoft Windows Server 2012 R2, SuSE Linux Enterprise Server 11 SP4, Microsoft Windows Server 2016, Red Hat Enterprise Linux 7.3, Red Hat Enterprise Linux 6.9, SuSE Linux Enterprise Server 12 SP2, Red Hat Enterprise Linux 7.4, Red Hat Enterprise Linux 8.0, SuSE Linux Enterprise Server 11 SP4 with Xen, SuSE Linux Enterprise Server 12 SP2 with Xen, Red Hat Enterprise Linux 7.5, Microsoft Windows Server 2019, Red Hat Enterprise Linux 6.10, SUSE Linux Enterprise Server 15, VMware vSphere Hypervisor 6.5 (ESXi), VMware vSphere Hypervisor 6.7 (ESXi), SUSE Linux Enterprise Server 15 with Xen, Red Hat Enterprise Linux 7.6, SuSE Linux Enterprise Server 12 SP4, SUSE Linux Enterprise Server 15 SP1, Red Hat Enterprise Linux 8.1, Red Hat Enterprise Linux 7.7, SUSE Linux Enterprise Server 12 SP5, SUSE Linux Enterprise Server 12 SP5 with Xen, SUSE Linux Enterprise Server 15 SP1 with Xen, Red Hat Enterprise Linux 7.8, Red Hat Enterprise Linux 8.2, SuSE Linux Enterprise Server 12 SP4 with Xen, SUSE Linux Enterprise Server 15 SP2, SUSE Linux Enterprise Server 15 SP2 with Xen, VMware vSphere Hypervisor 6.5 (ESXi) Update 3, VMware vSphere Hypervisor 6.7 (ESXi) Update 3, Red Hat Enterprise Linux 8.3, VMware vSphere Hypervisor 6.7 (ESXi) Update 2, VMware vSphere Hypervisor 6.7 (ESXi) Update 1, VMware vSphere Hypervisor 6.5 (ESXi) Update 1, VMware vSphere Hypervisor 6.5 (ESXi) Update 2, Red Hat Enterprise Linux 7.9, Red Hat Enterprise Linux 8.4, SUSE Linux Enterprise Server 15 SP3, SUSE Linux Enterprise Server 15 SP3 with Xen, Red Hat Enterprise Linux 8.5, Red Hat Enterprise Linux 8.6, Ubuntu 22.04 LTS |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Dimensions & Weight | |
| Depth | 11.7 cm |
| Height | 3 cm |
| Weight | 18 g |
Features - Lenovo - 4Y37A90063
More Details
Product Code
CK92839
EAN Code
0889488705085
Manufacturer
Lenovo
