LevelOne 4 GE POE+1 GE (GEP-0520)

LevelOne Y982592

Hover over an image to enlarge

(Including VAT)
5 item(s)
Product Code:Y982592
EAN Code:4015867158135

Free Store

Delivery within 2-4
business days

2 Years Warranty

LevelOne GEP-0520 LevelOne 4 GE POE+1 GE (GEP-0520)

LevelOne 4 GE POE+1 GE (GEP-0520)


- Complies with IEEE 802.3, 802.3u, 802.3ab and 802.3af
- 5-port 10/100/1000Mbps Ethernet with 4-port PoE Switch
- Provide 5 10/100/1000Mbps auto-detect with half/full duplex switch ports
- Provides 4 PoE ports with classification identify
- Supports 15.4W Maximum per PoE port

Advanced PoE Solution
The LevelOne GEP-0520 -Z is a high-performance 10/100/1000Mbps Gigabit PoE Switch with 4 Gigabit PoE ports 1 Gigabit uplink port. Each PoE port is powered up to 15.4W. The total PoE power budget is 61.6W. It is an ideal solution for office and home users to utilize a combination of PoE and non-PoE devices. The switch automatically detects IEEE 802.3af compliant devices and provides power and data over a single cable.

GEP-0520 -Z is compact in size, making it ideal for desktop users with limited space. You also have the option of installing several GEP-0520 -Z in a 19” chassis POC-6000 for a large-scale rack-mount PoE Solution.

Stable and Reliable Network Environment
GEP-0520 -Z enables users to deploy a stable and reliable high-speed LAN environment, with store-and-forward switching architecture, the GEP-0520 -Z provides a stable and reliable packet error fitering and non-blocking packet forwarding architecture. This device supports N-way auto-negotiation protocol which automatically detects networking speed and duplex modes.

Easy to Use
For instant error detection, the GEP-0520 -Z is equipped with LED Indicators to define problems on the network.

Feature list

Basic switching RJ-45 Ethernet ports quantity: 5
Copper ethernet cabling technology: 1000BASE-T, 100BASE-TX, 10BASE-T
Gigabit Ethernet copper ports quantity: 5
ExpressCard slot: N
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Full duplex: Y
10G support: N
MAC address table: 1024 entries
Supported data transfer rates: 10/100/1000 Mbps
Switching capacity: 10 Gbit/s
Store-and-forward: Y
Maximum data transfer rate: 1000 Gbit/s
Colour of product: Grey
LED indicators: Y
Certification: FCC, CE
Packet buffer memory: 104 MB
Power consumption typical: 61.6 W
Input voltage: 100 - 240 V
Power over Ethernet PoE support: Y
Operating temperature T-T: 0 - 50 °C
Operating relative humidity H-H: 10 - 90 %
Weight: 1200 g
Dimensions WxDxH: 90 x 120 x 28 mm
Connectivity technology: Wired
Installed ports: 5
Networking features: Gigabit Ethernet
Wi-Fi: N
Input frequency: 50 - 60 Hz
